Panasonic CQ-TX5500W

Ref.
No.
Part No. Part Name & Description Remarks
R516 ERJ3GEYJ563V Chip, 56kΩ
ΩΩ
Ω 1/16W
R517 ERJ3GEYJ271V Chip, 270Ω
ΩΩ
Ω 1/16W
R521 ERJ3GEYJ103V Chip, 10kΩ
ΩΩ
Ω 1/16W
R522 ERJ3GEYJ121V Chip, 120Ω
ΩΩ
Ω 1/16WW
R523 ERJ3GEYJ121V Chip, 120Ω
ΩΩ
Ω 1/16W
R524 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω 1/16W
R525 ERJ3GEYJ121V Chip, 120Ω
ΩΩ
Ω 1/16W
R526 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω 1/16W
R527 ERJ3GEY0R00V Chip, 0Ω
ΩΩ
Ω 1/16W
R528 ERJ3GEYJ152V Chip, 1.5kΩ
ΩΩ
Ω 1/16W
R529 ERJ3GEYJ152V Chip, 1.5kΩ
ΩΩ
Ω 1/16W
R530 ERJ3GEYJ152V Chip, 1.5kΩ
ΩΩ
Ω 1/16W
R531 ERJ6GEY0R00V Chip, 0Ω
ΩΩ
Ω 1/10W
R551 ERJ6GEYJ470 Chip, 47Ω
ΩΩ
Ω 1/10W
R901 ERJ3GEYJ392V Chip, 3.9kΩ
ΩΩ
Ω 1/16W
R902 ERJ3GEYJ122V Chip, 1.2kΩ
ΩΩ
Ω 1/16W
R903 ERJ3GEYJ392V Chip, 3.9kΩ
ΩΩ
Ω 1/16W
R904 ERJ3GEYJ122V Chip, 1.2kΩ
ΩΩ
Ω 1/16W
R905 ERJ3GEYJ682V Chip, 6.8kΩ
ΩΩ
Ω 1/16W
R906 ERJ3GEYJ682V Chip, 6.8kΩ
ΩΩ
Ω 1/16W
R907 ERJ3GEYJ472V Chip, 4.7kΩ
ΩΩ
Ω 1/16W
R908 ERJ3GEYJ223V Chip, 22kΩ
ΩΩ
Ω 1/16W
R909 ERJ3GEYJ682V Chip, 6.8kΩ
ΩΩ
Ω 1/16W
R910 ERJ3GEYJ123V Chip, 12kΩ
ΩΩ
Ω 1/16W
R911 ERJ12YJ100H Chip, 10Ω
ΩΩ
Ω 1/2W
CONNECTORs
CN1 K1MN14B00028 Connector, 14P
CN101 YEAESFW15R1E Connector, 15P
CN901 K1MN05B00010 Connector, 5P
CN902 K1MN05B00009 Connector, 5P
SWITCHEs
SW2 K0L1BA000022 Switch
SW4 YEAS09275 Switch
CRYSTAL
XL501 YEXLSTCC737T Crystal OSC
CERAMIC FILTER
XL201 H2D169500005 Ceramic Filter
COILs
L101 YELTLM41P750 Coil
L401 YELTBLM1B601 Coil
L402 YELTBLM1B601 Coil
L501 EXCCET103U RF Coil
L901 YELTBLM21A10 Coil
L902 YELTBLM21A10 Coil
RESISTOR NETWORKs
R462 D1H810140004 Resistor Network
R463 D1H810140004 Resistor Network
R464 D1H810140004 Resistor Network
R465 D1H810140004 Resistor Network
R466 D1H810140004 Resistor Network
R472 D1H810140004 Resistor Network
R474 D1H810140004 Resistor Network
R476 D1H810140004 Resistor Network
PRINTINGs
YEFM283913 Operating Instructions
Ref.
No.
Part No. Part Name & Description Remarks
INSTALLATION PARTS
YEAJ02802A Power Cord
CR2025/1F Battery
YEP9BS1043 Screws
YEFX9992594 Remote Controller
YEFG02444 Front Brakect
YEFG02444 Front Brakect
MISCELLANEOUS
F1 XBB1F100NS5 Fuse, 10A
CN1 K1PB06A00011 Connector, 6P
CN2 K9ZZ00000854 Connector, 14P
CN4 K9ZZ00000853 Connector, 30P
AJ1 YEAJ071285 Cord
AJ2 YEAJ071285 Cord
AJ10 YEAJ09344 Cord
ANT451 YEAA10066 Antenna Receptacle
AP1 YEAP2711 Flexible P.C.B
AT1 YEATSD00405 Terminal [E-9068B]
AT2 YEATSD00405 Terminal [E-9068B]
AT1 YEAT03435 Terminal [E-6904Aa]
AT2 YEAT03435 Terminal [E-6904Aa]
AT3 YEAT03435 Terminal
AT4 YEAT03435 Terminal
AT5 YEAT03435 Terminal
AT805 YEAT03435 Terminal
AT806 YEAT03435 Terminal
AT851 YEAT03435 Terminal
AT852 YEAT03435 Terminal
AT991 YEAT03435 Terminal
AT992 YEAT03435 Terminal
FAN1 L6FAGA9D0015 DC Motor
1 YEFV03732 Shield Case (Upper)
2 YEFX0215195 Bracket, CD Deck
3 YEFX0215969 Bracket, IC852
4 YEFM031269 Seal, Danger
6 YEFX007565 Cord Clamper
7 YEFR04623 Lead Cap
8 YEFA031795 Upper Cover
9 YEFA08546 Rear Plate
10 YEFF011026A Heat Sink
11 YEFV03731 Shield Case (Lower)
12 YEFX0215944 Bracket, IC712
13 YEFX0215199 Bracket, IC306
14 YEFX0212830 Bracket, Q720
15 YEFX0214977 Bracket, RCA/REG
16 YEFX0215200 Bracket, ANT451
17 YEFA07552A Front Plate
18 YEFA09734 Side Bracket (L)
19 YEFF01982 Heat Sink
20 YEFC027696 Escutcheon Ass´y
21 YEFN99413 Panel Ass´y
22 YEFE07510 Knob, TUNE/TRACK
23 YEFE07491A Knob, VOL
24 YEFX9992774 Vacuum Tube
25 XNG3GFX Nut
26 YEFX9992587 Double Side Adhesive Tape
27 YEFX0012140A Transparent Plate
28 YEFX0012139A Transparent Plate
29 YEFX0215943 Bracket, LCD
30 YEFV021885 Optical Shade
31 YEFX0012247 Transparent Plate
32 YEFX9992802 Reflection Sheet
33 YEFR07146 Rubber Contact
34 YEFK061038 Holder, LCD
35 YEFX0012246 Transparent Plate
36 YEFS02339 Felt
37 YEFX233516 Bracket, Dust Felt
40 YEP9FX181 Analog Meter Ass´y
