Panasonic CS-BZ35XKE - Page 150

150
SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CU-BZ25XKE CU-BZ35XKE REMARK
1 CHASSIS COMPLETE 1 ACXD52K00150 ←
2 SOUND PROOF MATERIAL (TOP) 1 CWG302737 ←
3 FAN MOTOR BRACKET 1 CWD541157 ←
4 SCREW - FAN MOTOR BRACKET 2 ACXH55-07140 ←
5
FAN MOTOR 1 L6CAYYYL0124 ← O
6 SCREW - FAN MOTOR MOUNT 4 CWH55252J ←
7 PROPELLER FAN ASSY 1 CWH03K1100 ←
8 NUT - PROPELLER FAN 1 CWH56053J ←
9
COMPRESSOR 1 9GS064XAA21 9GS075XAA21 O
10 ANTI - VIBRATION BUSHING 3 ACXH50-00140 ←
11 NUT - COMPRESSOR MOUNT 3 CWH561096 ←
12 CONDENSER 1 ACXB32C14790 ACXB32C19940
13 EXPANSION VALVE 1 ACXB05-01080 ←
14 DISCHARGE MUFFLER (4 W. VALVE) 2 CWB121010 ←
15 HOLDER COUPLING 1 CWH351233 ←
16 2-WAYS VALVE (LIQUID) 1 ACXB02-03370 ← O
17 3-WAY VALVE (GAS) 1 ACXB01-04550 ← O
19
REACTOR 1 G0C752J00004 ← O
20 TERMINAL COVER 1 CWH171041 ←
22 SOUND PROOF BOARD 1 CWH151427 ←
23 SOUND PROOF MATERIAL 1 ACXG30-11530 ←
24
SENSOR CO - COMP TEMP 1 ACXA50C17390 ← O
25 CONTROL BOARD COVER - TOP 1 ACXH13-00450 ←
26
ELECTRONIC CONTROLLER - MAIN 1 ACXA73C85080R ACXA73C85090R O
27
TERMINAL BOARD ASSY 1 CWA28K1036J ← O
28 CABINET SIDE PLATE CO. 1 ACXE04C05610 ←
29
SENSOR CO - AIR TEMP AND PIPE TEMP 1 CWA50C3079 ← O
30 CABINET SIDE PLATE 1 ACXE04-00130A ←
31 CABINET FRONT PLATE CO. 1 CWE06C1563 ←
32 CABINET TOP PLATE 1 CWE031230A ←
33 PLATE - C. B. COVER TERMINAL 1 CWH131301 ←
34 CONTROL BOARD COVER CO. 1 CWH13C1359 ←
38 4-WAYS VALVE 1 ACXB00-01290 ← O
39
V-COIL COMPLETE (4-WAY VAL
VE)
1 ACXA43C00250 ← O
40 O-RING 1 ACXB81-06510 ←
41
ACCESSORY - COMPLETE
1 ACXH82C21740 ←
42
V-COIL COMPLETE (EXP. VALVE
)
1 ACXA43C06110 ← O
43 STRAINER 1 CWB11094 ←
44 DISCHARGE MUFFLER 1 CWB121021 ←
46 PANASONIC BADGE 1 CWE373439 ←
48 OPERATING INSTRUCTION 1 ACXF55-32840 ←
49 OPERATING INSTRUCTION 1 ACXF55-32850 ←
50 OPERATING INSTRUCTION 1 ACXF55-32700 ←
51 OPERATING INSTRUCTION 1 ACXF55-32860 ←
52 INSTALLATION INSTRUCTION 1 ACXF60-45950 ←
53 INSTALLATION INSTRUCTION 1 ACXF60-45960 ←
54 INSTALLATION INSTRUCTION 1 ACXF60-45970 ←
55 INSTALLATION INSTRUCTION 1 ACXF60-45980 ←
56 INSTALLATION INSTRUCTION 1 ACXF60-45990 ←
