Panasonic CS-E28NKR Service Manual

204
REF. NO. DESCRIPTION & NAME QTY. CU-E28NKR REMARK
1 BASE PAN ASS'Y 1 CWD52K1295
2 COMPRESSOR 1 5KD240XAF21 O
3 ANTI - VIBRATION BUSHING 3 CWH50055
4 NUT - COMPRESSOR MOUNT 3 CWH561049
5 PACKING 3 CWB811017
6 CRANKCASE HEATER 1 CWA341080
7 CONDENSER COMPLETE 1 CWB32C3300
8 SOUND PROOF MATERIAL 1 CWG302246
9 DISCHARGE MUFFLER 1 CWB121013
11 3 WAYS VALVE (GAS) 1 CWB011251 O
12 4 WAYS VALVE 1 CWB001026J
13 2 WAYS VALVE (LIQUID) 1 CWB021330 O
14 STRAINER 2 CWB111032
18 SOUND PROOF MATERIAL 1 CWG302245
19 SOUND PROOF BOARD 1 CWH151294
20 V-COIL COMPLETE - 4-WAY VALVE 1 CWA43C2169J
21 V-COIL COMPLETE - EXP.VALVE 1 CWA43C2128J
23 SENSOR CO. - COMP TEMP 1 CWA50C2656 O
24 SENSOR CO. - AIR AND COND TEMP 1 CWA50C2652 O
25 CABINET REAR PLATE - COMPLETE 1 CWE02C1043
26 CONTROL BOARD A'SSY 1 CWH10K1158
27 TERMINAL BOARD ASSY 1 CWA28K1162 O
28 TERMINAL BOARD ASSY 1 CWA28K1076J O
30 ELECTRONIC CONT. - CAPACITOR 1 CWA746775 O
31 ELECTRONIC CONTROLLER - NF 1 CWA746758 O
33 ELECTRONIC CONTROLLER - MAIN 1 CWA73C6934R O
34 REACTOR 1 G0C452J00002
36 TERMINAL COVER 1 CWH171039A
37 NUT - TERMINAL COVER 1 CWH7080300J
38 FAN MOTOR BRACKET 1 CWD54K1063
39 SCREW - FAN MOTOR BRACKET 2 CWH551040J
40 FAN MOTOR (UPPER) 1 ARW8405AC O
40a FAN MOTOR (BOTTOM) 1 ARW8406AC O
41 SCREW - FAN MOTOR MOUNT 8 CWH55252J
42 PROPELLER FAN ASS’Y 2 CWH03K1065
43 NUT - PROPELLER FAN 2 CWH56053J
44 CABINET FRONT PLATE ASSY 1 CWE06C1408
45 DISCHARGE GRILLE 2 CWE201075
46 CABINET SIDE PLATE ASS'Y 1 CWE04K1022A
47 WIRE NET 1 CWD041129A
48 CABINET TOP PLATE 1 CWE03C1095
49 ACCESSORY CO. (DRAIN ELBOW) 1 CWG87C900
51 L-SHAPED PLATE (FRONT) 1 CWD601074A
52 L-SHAPED PLATE (BACK) 1 CWD601075A
53 CABINET FRONT PLATE 1 CWE061092A
59 HOLDER SENSOR 3 CWH711010
61 EXPANSION VALVE 1 CWB051018J
62 INSTALLATION INSTRUCTION 1 CWF615542
63 OPERATING INSTRUCTION 1 CWF568746
64 ELECTRONIC CONTROLLER 1 CWA746558 O
65 TERMINAL BOARD ASSY 1 CWA28K1281 O
66 RECEIVER 1 CWB14017
67 BAG 1 CWG861239
68 BASE BOARD - COMPLETE 1 CWG62C1086
69 SHOCK ABSORBER (RIGHT) 2 CWG712852
