Panasonic CS-E9NKDW User Manual

12
Type Cross-flow Fan
Material ASG30K1
Motor Type Transistor (8-poles)
Input Power W 94.8
Output Power W 40
Cool rpm 960
QLo
Heat rpm 1040
Cool rpm 1040
Lo
Heat rpm 1120
Cool rpm 1160
Me
Heat rpm 1240
Cool rpm 1280
Hi
Heat rpm 1360
Cool rpm 1390
Indoor Fan
Speed
SHi
Heat rpm 1430
Type Propeller Fan
Material PP
Motor Type Induction (6-poles)
Input Power W -
Output Power W 40
Cool rpm 660
Outdoor Fan
Speed Hi
Heat rpm 640
Moisture Removal L/h (Pt/h) 2.8 (5.9)
Cool m
3
/min (ft
3
/min) 12.0 (424)
QLo
Heat m
3
/min (ft
3
/min) 13.2 (466)
Cool m
3
/min (ft
3
/min) 13.2 (466)
Lo
Heat m
3
/min (ft
3
/min) 14.3 (505)
Cool m
3
/min (ft
3
/min) 14.9 (526)
Me
Heat m
3
/min (ft
3
/min) 16.0 (565)
Cool m
3
/min (ft
3
/min) 16.3 (575)
Hi
Heat m
3
/min (ft
3
/min) 17.9 (630)
Cool m
3
/min (ft
3
/min) 18.1 (639)
Indoor
Airflow
SHi
Heat m
3
/min (ft
3
/min) 18.5 (653)
Cool m
3
/min (ft
3
/min) 39.2 (1385)
Outdoor
Airflow
Hi
Heat m
3
/min (ft
3
/min) 37.9 (1340)
Control Device Expansion Valve
Refrigerant Oil cm
3
FV50S (450)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 1.22k (43.1)
Height (I/D / O/D) mm (inch) 290 (11-7/16) / 695 (27-3/8)
Width (I/D / O/D) mm (inch) 1070 (42-5/32) / 875 (34-15/32)
Dimension
Depth (I/D / O/D) mm (inch) 240 (9-15/32) / 320 (12-5/8)
Weight Net (I/D / O/D) kg (lb) 11 (24) / 46 (101)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 12.70 (1/2)
Standard Length m (ft) 5 (16.4)
Length Range (min – max) m (ft) 3 (9.8) ~ 20 (65.5)
I/D & O/D Height Different m (ft) 15.0 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Piping
Length for Additional Gas m (ft) 7.5 (24.6)
