Type Cross-flow Fan Cross-flow Fan
Material ASG20K1 ASG20K1
Motor Type Transistor (8-poles) Transistor (8-poles)
Input Power W 94.8 94.8
Output Power W 40 40
Cool rpm 590 630
QLo
Heat rpm 680 670
Cool rpm 670 730
Lo
Heat rpm 730 820
Cool rpm 860 950
Me
Heat rpm 910 1030
Cool rpm 1050 1180
Hi
Heat rpm 1090 1240
Cool rpm 1110 1240
Indoor Fan
Speed
SHi
Heat rpm 1150 1280
Type Propeller Fan Propeller Fan
Material PP PP
Motor Type Induction (6-poles) Induction (6-poles)
Input Power W - -
Output Power W 25 25
Outdoor Fan
Speed Hi rpm 730 750 750 770
Moisture Removal L/h (Pt/h) 1.3 (2.7) 1.5 (3.2)
Cool m
3
/min (ft
3
/min) 5.6 (198) 4.9 (173)
QLo
Heat m
3
/min (ft
3
/min) 6.0 (212) 5.3 (187)
Cool m
3
/min (ft
3
/min) 6.5 (230) 6.0 (212)
Lo
Heat m
3
/min (ft
3
/min) 7.2 (254) 7.1 (251)
Cool m
3
/min (ft
3
/min) 8.7 (307) 8.7 (307)
Me
Heat m
3
/min (ft
3
/min) 9.3 (328) 9.6 (339)
Cool m
3
/min (ft
3
/min) 10.9 (385) 11.3 (400)
Hi
Heat m
3
/min (ft
3
/min) 11.4 (400) 11.9 (420)
Cool m
3
/min (ft
3
/min) 11.6 (410) 11.7 (410)
Indoor
Airflow
SHi
Heat m
3
/min (ft
3
/min) 12.0 (424) 12.1 (427)
Cool m
3
/min (ft
3
/min) 32.4 (1145) - 33.9 (1195) 29.4 (1040) - 29.8 (1050)
Outdoor
Airflow
Hi
Heat m
3
/min (ft
3
/min) 32.4 (1145) - 33.9 (1195) 29.4 (1040) - 29.8 (1050)
Control Device Check Valve & Capillary Tube Check Valve & Capillary Tube
Refrigerant Oil cm
3
FV50S (320) FV50S (320)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 830 (29.3) R410A, 960 (33.9)
Height (I/D / O/D) mm (inch) 290 (11-7/16) / 542 (21-11/32) 290 (11-7/16) / 542 (21-11/32)
Width (I/D / O/D) mm (inch) 870 (34-9/32) / 780 (30-23/32) 870 (34-9/32) / 780 (30-23/32)
Dimension
Depth (I/D / O/D) mm (inch) 214 (8-7/16) / 289 (11-13/32) 214 (8-7/16) / 289 (11-13/32)
Weight Net (I/D / O/D) kg (lb) 9 (20) / 31 (68) 9 (20) / 33 (73)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 9.52 (3/8)
Standard Length m (ft) 5 (16.4) 5 (16.4)
Length Range (min – max) m (ft) 3 (9.8) ~ 15 (49.2) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height Different m (ft) 15.0 (49.2) 15.0 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2) 20 (0.2)
Piping
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
