Mounting Remote Controller Receiver
Install the remote controller receiver cable at least 1 31/32" (50 mm) away from electric wires of other appliances to avoid miss-operation
(electromagnetic noise).
1
Remove the bottom case.
Insert the driver
and slightly turn.
Bottom
case
Flat-blade
screwdriver
At
tention
Mounting the bottom case
x Tighten the screws securely until the screw head
s
touch the b
ottom case. (Otherwise, loose scre
w
head
s may hit the PCB and cause malfunction
when mounting the top ca
se.)
x
Do not over-tighten the screws. (The bottom ca
se
may be deformed, re
sultin
g in fall of the unit.)
Screws
6
Con
necting the remote control wiring
x Arrange the wires as shown in the illustration for 2 as in diagram below, avoiding unnecessary wires bei
ng
store
d in the case. (Caught wires ma
y destroy the PCB.)
x
Avoid wires touching parts on the PCB. (Caught wires may destro
y the PCB.)
2
Mount to the wall.
EXPOSED TYPE
Prepara
tion: Make 2 holes for screws using a driver.
Mount the top case.
• Align the claws of the
top case and then align
the claws of the bottom
case.
Mount the bottom case
to the wall.
Connect the remote control wiring.
• Arrange the wires along the groove of the case.
Cut here with
a nipper and
remove the burr
with a fi
le.
Hole for screw
Claw (2 places)
Wall to fi x the
receiver
Wood screw (supplied)
Claw
Clamper
7
(supplied)
Pass
through
the hole
Top case
(Back side)
Bottom case (Back side)
EMBEDDED TYPE
Prepara
tion: Make 2 holes for screws using a driver.
Mount the top case.
• Align the claws of the
top case and then
align the claws of the
bottom case.
Mount the bottom case to the wall.
• Pass the wire through the hole in
the centre of the bottom case.
Connect the remote control wiring.
Avoid the wire
being caught.
Claw (2 places)
Hole for screw
Claw
Wood screw (supplied)
Terminal board
Top case
(Back side)
Bottom case (Back side)
To Next Page
