Panasonic CS-HZ25UKE Service Manual

11
Model
Indoor CS-HZ25UKE / CS-HZ25UKE-5
Outdoor CU-HZ25UKE / CU-HZ25UKE-5
Indoor Fan
Type Cross-Flow Fan
Material ASG33
Motor Type DC / Transistor (8-poles)
Input Power W 47.3
Output Power W 40
Speed
QLo
Cool rpm 540
Heat rpm 550
Lo
Cool rpm 640
Heat rpm 700
Me
Cool rpm 920
Heat rpm 1020
Hi
Cool rpm 1200
Heat rpm 1300
SHi
Cool rpm 1270
Heat rpm 1370
Outdoor Fan
Type Propeller Fan
Material PP
Motor Type DC Motor (8-poles)
Input Power W –
Output Power W 40
Speed Hi
Cool rpm 850
Heat rpm 850
Moisture Removal L/h (Pt/h) 1.5 (3.2)
Indoor Airflow
QLo
Cool m
3
/min (ft
3
/min) 5.95 (210)
Heat m
3
/min (ft
3
/min) 6.07 (214)
Lo
Cool m
3
/min (ft
3
/min) 7.19 (254)
Heat m
3
/min (ft
3
/min) 7.94 (280)
Me
Cool m
3
/min (ft
3
/min) 10.56 (373)
Heat m
3
/min (ft
3
/min) 12.07 (426)
Hi
Cool m
3
/min (ft
3
/min) 14.00 (495)
Heat m
3
/min (ft
3
/min) 15.60 (550)
SHi
Cool m
3
/min (ft
3
/min) 14.86 (525)
Heat m
3
/min (ft
3
/min) 16.48 (582)
Outdoor
Airflow
Hi
Cool m
3
/min (ft
3
/min) 32.70 (1155)
Heat m
3
/min (ft
3
/min) 32.70 (1155)
Refrigeration
Cycle
Control Device Expansion Valve
Refrigerant Oil cm
3
FW50S (450)
Refrigerant Type g (oz) R32, 1.12k (39.5)
F-Gas
GWP 675
PRECHARGED AMOUNT /
MAXIMUM CHARGE AMOUNT
CO2eq (ton) 0.756 / 0.925
Dimension
Height (I/D / O/D) mm (inch) 295 (11-5/8) / 622 (24-1/2)
Width (I/D / O/D) mm (inch) 870 (34-9/32) / 824 (32-15/32)
Depth (I/D / O/D) mm (inch) 230 (9-1/16) / 299 (11-25/32)
Weight Net (I/D / O/D) kg (lb) 10 (22) / 36 (79)
Piping
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8)
Standard length m (ft) 5.0 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 20 (65.6)
I/D & O/D Height different m (ft) 10.0 (32.8)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Length for Additional Gas m (ft) 7.5 (24.6)
