125
REF.
NO.
PART NAME & DESCRIPTION QTY. CS-S9NKV CS-S12NKV REMARK
1 CHASSIS COMPLETE 1 CWD50C1666 ←
2 FAN MOTOR 1 CWA921443 ← O
3 CROSS-FLOW FAN COMPLETE 1 CWH02C1076 ←
4 BEARING ASSY 1 CWH64K007 ←
5 SCREW - CROSS-FLOW FAN 1 CWH551146 ←
6 GENERATOR COMPLETE 1 CWH94C0043 ←
7 EVAPORATOR 1 CWB30C3646 CWB30C3396
8 FLARE NUT (LIQUID) 1 CWT251030 ←
9 FLARE NUT (GAS) 1 CWT251031 CWT251032
10 CLIP FOR SENSOR 1 CWH32143 ←
11 CONTROL BOARD CASING 1 CWH102449 ←
12 TERMINAL BOARD COMPLETE 1 CWA28C2435 CWA28C2437 O
13 ELECTRONIC CONTROLLER - MAIN 1 CWA73C6245 CWA73C6246 O
14 ELECTRONIC CONTROLLER - HVU 1 N0GE1F000002 ← O
15 ELECTRONIC CONTROLLER - INDICATOR 1 CWA746634 ← O
16 SENSOR COMPLETE 1 CWA50C2401 ← O
17 SENSOR COMPLETE (ECO) 1 CWA50C2809 ← O
18 ELECTRONIC CONTROLLER (ECO SENSOR) 1 CWA745791 ← O
19 ELECTRONIC CONTROLLER (ECO SENSOR) 1 CWA746206 ← O
20 ELECTRONIC CONTROLLER (COMPARATOR) 1 CWA746653 ← O
21 LEAD WIRE - PCB ECO 1 CWA67C9785 ←
22 CONTROL BOARD CASING FOR PCB ECO 1 CWD933407 ←
23 CONTROL BOARD TOP COVER 1 CWH131467 ←
24 INDICATOR HOLDER 1 CWD933406 ←
25 CONTROL BOARD FRONT COVER CO. 1 CWH13C1247 ←
26 DISCHARGE GRILLE COMPLETE 1 CWE20C3234 ←
27 BACK COVER CHASSIS 1 CWD933233A ←
28 FULCRUM 1 CWH621131 ←
29 VERTICAL VANE 8 CWE241374 ←
30 CONNECTING BAR 1 CWE261250 ←
31 CONNECTING BAR 1 CWE261256 ←
32 AIR SWING MOTOR 1 CWA98K1016 ← O
33 AIR SWING MOTOR 1 CWA981264 ← O
34 CAP - DRAIN TRAY 1 CWH521096 ←
35 HORIZONTAL VANE COMPLETE 1 CWE24C1384 ←
36 REMOTE CONTROL COMPLETE 1 CWA75C3865 ← O
37 FRONT GRILLE COMPLETE 1 CWE11C5078 ← O
38 INTAKE GRILLE COMPLETE 1 CWE22C1731 ←
39 GRILLE DOOR COMPLETE 1 CWE14C1091 ←
40 AIR FILTER 2 CWD001279 ←
41 SCREW - FRONT GRILLE 2 XTT4+16CFJ ←
42 CAP - FRONT GRILLE 2 CWH521227A ←
43 DRAIN HOSE 1 CWH851174 ←
44 INSTALLATION PLATE 1 CWH361097 ←
45 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1705 ←
46 OPERATING INSTRUCTION 1 CWF568408 ←
47 INSTALLATION INSTRUCTION 1 CWF615273 ←
48 INSTALLATION INSTRUCTION 1 CWF615274 ←
49 POWER SUPPLY CORD 1 CWA20C3054 ←
