Panasonic CS-UE9PKE Service Manual

7
Indoor CS-RE15PKE-3
Model
Outdoor CU-RE15PKE-3
Phase, Hz Single, 50
Power Supply
V 230
Min Rate Max
kW 1.00 4.20 4.60
BTU/h 3410 14330 15700
Capacity
kcal/h 860 3610 3960
Running Current A - 6.00 -
Input Power W 210 1260 1650
W/W 4.76 3.33 2.78
BTU/hW 16.23 11.37 9.51
EER
kcal/h/W 4.09 2.86 2.40
Pdesign C kW - 4.2 -
SEER (W/W) - 5.6 -
Annual Consumption kWh - 263 -
Erp
Class - - A+ -
Power Factor % 91
dB-A(H / L / QLo) Hi: 44 Lo: 31 QLo: 29
Indoor Noise
Power Level 60
dB-A (H / L ) Hi: 49 Lo: -
COOLING
Outdoor Noise
Power Level 65
kW 0.90 5.00 6.80
BTU/h 3070 17060 23200
Capacity
kcal/h 770 4300 5850
Running Current A - 6.30 -
Input Power W 210 1385 2280
W/W 4.28 3.61 2.98
BTU/hW 14.61 12.31 10.17
COP
kcal/hW 3.66 3.10 2.56
Pdesign H(A) kW - 3.6 -
Tbivalent
℃
- -10 -
SCOP (W/W) - 3.4 -
Annual Consumption kWh - 1482 -
Erp
Class - - A -
Power Factor % 95
dB-A(H / L / QLo) Hi: 46 Lo: 34 QLo: 28
Indoor Noise
Power Level 62
dB-A (H / L ) Hi: 51 Lo: -
HEATING
Outdoor Noise
Power Level 67
Max Current (A) / Max Input Power (W) 10.5 / 2.280k
Starting Current (A) 6.40
Standby Power (W) 7.5
Type Hermetic Motor compressor
Motor Type BRUSHLESS (6 poles)
Compressor
Output Power W 1100
Type Cross-flow fan
Material AS(GF30%)
Motor Type DC (8 poles)
Input Power W 36.66
Output Power W 30
Q-Lo rpm 730
Lo rpm 800
Me rpm 1020
Speed
(COOLING)
Hi rpm 1250
Q-Lo rpm 740
Lo rpm 900
Me rpm 1060
Indoor Fan
Speed
(HEATING)
Hi rpm 1300
Type Propeller
Material PP
Motor Type DC (8 poles)
Outdoor Fan
Input Power W 132.77
