114
17.1.6 To Remove Indicator Flap and Electronic Controller (Indicator)
Drain Pan
Indicator Flap
Tab
Indicator FlapParticular Piece
Hook
1. Detach 1 connector from electronic controller (Indicator).
2. Release the tab and remove the electronic controller (Indicator) by detach the connector. Release the tab
and pull the electronic controller out.
3. Unhook the indicator flap from the drain pan.
17.1.7 To Remove Electronic Controller (Receiver)
Tab
Electronic Controller
1. Detach 1 connector from electronic controller (Receiver).
2. Release the tab and remove.
To Next Page
