Panasonic CS-YE18MKE Service Manual

5
2. Specification
Indoor CS-YE9MKE CS-YE12MKE
Model
Outdoor CU-YE9MKE CU-YE12MKE
Phase, Hz Single, 50 Single, 50
Power Supply
V 230 230
Min Rate Max Min Rate Max
kW 0.90 2.50 3.00 0.900 3.300 3.900
BTU/h 3070 8530 10230 3070 11250 1330
Capacity
kcal/h 770 2150 2580 770 2840 3350
Running Current A - 3.60 - - 4.90 -
Input Power W 190 760 1000 200 1020 1300
W/W 4.73 3.28 3.00 4.50 3.23 3.00
EER
BTU/hW 16.15 11.22 10.23 15.35 11.02 10.23
Power Factor % 91 90
dB-A (H / L / QLo) Hi: 40 Lo: 27 QLo: 22 Hi: 42 Lo: 30 QLo: 22
Indoor Noise
Power Level 56 58
dB-A (H / L ) Hi: 47 Lo: - Hi: 48 Lo: -
COOLING
Outdoor Noise
Power Level 63 64
kW 0.90 3.20 4.20 0.90 4.00 5.00
BTU/h 3070 10900 14320 3070 13640 17050
Capacity
kcal/h 770 2750 3610 770 3440 4300
Running Current A - 4.10 - - 5.20 -
Input Power W 190 880 1200 200 1105 1420
W/W 4.73 3.63 3.50 4.50 3.61 3.52
COP
BTU/hW 16.15 12.38 11.93 15.35 12.34 12.00
Power Factor % 93 92
dB-A (H / L / QLo) Hi: 40 Lo: 27 QLo: 23 Hi: 42 Lo: 33 QLo: 25
Indoor Noise
Power Level 56 58
dB-A (H / L ) Hi: 48 Lo: - Hi: 50 Lo: -
HEATING
Outdoor Noise
Power Level 64 66
Max Current (A) / Max Input Power (W) 5.80 / 1.200k 8.80 / 1.600k
Starting Current (A) 3.70 5.40
Type Hermetic Motor Hermetic Motor
Motor Type BRUSHLESS (6 poles) BRUSHLESS (6 poles)
Compressor
Output Power W 750 900
Type Cross-flow fan Cross-flow fan
Material AS AS
Motor Type AC (4 poles) AC (4 poles)
Input Power W 55 59.73
Output Power W 25 25
Q-Lo rpm 630 670
Lo rpm 740 830
Me rpm 900 990
Speed
(COOLING)
Hi rpm 1070 1170
Q-Lo rpm 660 720
Lo rpm 750 930
Me rpm 910 1050
Indoor Fan
Speed
(HEATING)
Hi rpm 1070 1200
Type Propeller Propeller
Material PP PP
Motor Type AC (6 poles) AC (6 poles)
Input Power W 64.9 82.61
Output Power W 25 40
Hi(C) rpm 650 730
Outdoor Fan
Speed
Hi(H) rpm 650 730
Moisture Removal L/h (Pt/h) 1.4 (2.4) 1.9 (3.3)
Q-Lo m
3
/min (ft
3
/m) 7.38(260) 7.70 (272)
Lo m
3
/min (ft
3
/m) 8.63(304) 9.59 (339)
Me m
3
/min (ft
3
/m) 10.5(370) 11.48 (405)
Indoor Airflow
(COOLING)
Hi m
3
/min (ft
3
/m) 12.5 (441) 13.5 (477)
Indoor Airflow Q-Lo m
3
/min (ft
3
/m) 8.06(285) 8.34 (295)
