Panasonic CS-Z25UFEAW Service Manual

13
Model
Indoor CS-Z50UD3EAW CS-Z60UD3EAW
Outdoor CU-Z50UBEA CU-Z60UBEA
Performance Test Condition EUROVENT EUROVENT
Power Supply
Phase, Hz Single, 50 Single, 50
V 230 230
Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 0.90 5.10 5.70 0.90 6.00 6.50
BTU/h 3070 17400 19400 3070 20500 22200
Kcal/h 770 4390 4900 770 5160 5590
Running Current A – 6.90 – – 9.00 –
Input Power W 255 1.56k 1.78k 255 2.04k 2.30k
Annual Consumption kWh – 780 – – 1020 –
EER
W/W 3.53 3.27 3.20 3.53 2.94 2.83
BTU/hW 12.04 11.15 10.90 12.04 10.05 9.65
Kcal/hW 3.02 2.81 2.75 3.02 2.53 2.43
ErP
Pdesign kW 5.1 6.0
SEER (W/W) 5.9 5.6
Annual
Consumption
kWh 303 375
Class A+ A+
Power Factor % – 98 – – 99 –
Indoor Noise (H / L / QLo)
dB-A 39 / 29 / 26 41 / 30 / 27
Power Level dB 55 / – 57 / –
Outdoor Noise (H / L)
dB-A 48 / – 49 / –
Power Level dB 63 / – 64 / –
Heating
Capacity
kW 0.90 6.10 7.20 0.90 7.00 8.00
BTU/h 3070 20800 24600 3070 23900 27300
Kcal/h 770 5250 6190 770 6020 6880
Running Current A – 8.00 – – 9.70 –
Input Power W 260 1.82k 2.20k 260 2.16k 2.60k
COP
W/W 3.46 3.35 3.27 3.46 3.24 3.08
BTU/hW 11.81 11.43 11.18 11.81 11.06 10.50
Kcal/hW 2.96 2.88 2.81 2.96 2.79 2.65
ErP
Pdesign kW 4.0 4.6
Tbivalent °C -10 -10
SCOP (W/W) 4.1 4.1
Annual
Consumption
kWh 1366 1571
Class A+ A+
Power Factor % – 99 – – 97 –
Indoor Noise (H / L / QLo)
dB-A 39 / 30 / 27 41 / 32 / 29
Power Level dB 55 / – 57 / –
Outdoor Noise (H / L)
dB-A 48 / – 50 / –
Power Level dB 63 / – 65 / –
Low Temp. : Capacity (kW) / I.Power (W) / COP 5.22 / 1.95k / 2.68 5.80 / 2.30k / 2.52
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 4.50 / 1.95k / 2.31 5.10 / 2.32k / 2.20
Max Current (A) / Max Input Power (W) 9.9 / 2.20k 12.3 / 2.70k
Starting Current (A) 8.00 9.70
