and outdoor air temp. 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.) / / / / / /
ELECTRICAL DATA (50Hz)
MODEL / ITEM
CS-A34BD2P/CU-C34BBP8
Condition by JIS B 8616
Volts V 380 400 415
Phase 3N 3N 3N
Input Power kW Cool 3.65 3.65 3.65
Running Current A Cool 6.5 6.5 6.5
Starting Current A 39 41 42
Power Factor % Cool 85 81 78
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power
source
AC, 3N~380V, 400V, 415V 50Hz
4.6 CS-A43BD2P / CU-C43BBP8
ITEM / MODEL
Indoor Unit Outdoor unit
Main Body CS-A43BD2P CU-C43BBP8
Cooling Capacity kW 13.00
(BTU/h) (44,300)
Refrigerant Charge-less m 30
Standard Air Volume for High
m
3
/min
Hi 50 Hi 82
Medium and Low Speed cfm Hi 1766 2895
External Static Pressure mmAq Hi 10 Me 5 Lo 0 -
Pa Hi 98 Me 49 Lo 0
Air Inlet Backward Suction Rear sided Suction
Air Outlet Front blow-out Front blow-out
Outside Dimension (H x W x D) mm 360 x (1000 + 10) x 650 1220 x 1100 x 320
49
