3.1 CS-A24BD2P / CU-A24BBP5
ITEM / MODEL
Indoor Unit Outdoor unit
Main Body CS-A24BD2P CU-A24BBP5
Cooling Capacity kW 6.50
(BTU/h) (22,200)
Heating Capacity kW 7.10
(BTU/h) (24,200)
Refrigerant Charge-less m 30
Standard Air Volume for High
Medium and Low Speed
m
3
/min
Hi 18 Hi 43
cfm Hi 636 1518
External Static Pressure mmAq Hi 10 Me 7 Lo 5 -
Pa Hi 98 Me 69 Lo 49
Air Inlet Backward Suction Rear sided Suction
Air Outlet Front blow-out Front blow-out
Outside Dimension (H x W x D) mm 290 x (1000 + 100) x 500 900 x 900 x 320
Net Weight kg (lbs) 43 (95) 80 (176)
Piping
Connection
Refrigerant
Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 6.35 (1/4) Flared Type
Drain mm Female screw RC1 (PT1) I.DØ 20 x 1
Compressor
Type, Number of Set - Hermetic-1 (Rotary), 1
Starting Method - Direct on-line starting
Motor Type - 2-pole single phase
induction motor
Input kW - Cool/Heat 2.31/2.30
Rated
Output
kW - 1.9
20
