ITEM / MODEL
Indoor Unit Outdoor unit
Main Body CS-A34BD2P CU-A34BBP8
Cooling Capacity kW 10.45
(BTU/h) (35,600)
Heating Capacity kW 11.20
(BTU/h) (38,200)
Refrigerant Charge-less m 30
Standard Air Volume for High
Medium and Low Speed
m
3
/min
Hi 35 Hi 70
cfm Hi 1236 2471
External Static Pressure mmAq Hi 10 Me 7 Lo 5 -
Pa Hi 98 Me 69 Lo 49
Air Inlet Backward Suction Rear sided Suction
Air Outlet Front blow-out Front blow-out
Outside Dimension (H x W x D) mm 360 x (1000 + 10) x 650 1220 x 900 x 320
Net Weight kg (lbs) 54 (119) 97 (214)
Piping
Connection
Refrigerant
Gas mm (inch) O.D Ø 19.05 (3/4) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm Female screw (PT1) I.DØ 20 x 1
Compressor
Type, Number of Set - Hermetic-1 (Scroll), 1
Starting Method - Direct on-line starting
Motor Type - 2-pole single phase
induction motor
Input kW - Cool/Heat 2.93/3.03
Rated
Output
kW - 2.8
30
