MODEL NAME RATED HEATING STANDARD
CAPACITY(kW) POWER CONSUMPTION(kW)
CS-A24BD2P/CU-A24BBP5 7.10 2.50
CS-A28BD2P/CU-A28BBP5 7.75 2.61
CS-A28BD2P/CU-A28BBP8 7.75 2.40
CS-A34BD2P/CU-A34BBP5 11.20 3.55
CS-A34BD2P/CU-A34BBP8 11.20 3.40
CS-A43BD2P/CU-A43BBP8 14.20 3.90
CS-A50BD2P/CU-A50BBP8 15.70 5.09
<Precautions on using capacity and electrical characteristics curves>
- Heating capacity when the unit is frosted over or while being defrosted will vary depending on
outdoor temperature ('CW8) and the amount c frost. Heating capacity performance must be
compensated because it does not take into account the capacity drop incurred when the unit is
frosted over and while it is being defrosted. Therefore, to obtain the integral heating capacity in
consideration 01 overfrosting and defrost operations. Heating capacity must be multiplied by the
compensation coefficient below.
- Heating capacity compensation coefficient for heating in frosted situations.
148
