Fan Type, Number of Set Sirocco fan-3 Prop. fan-2
Air Volume Control Three-Step and Auto mode -
(Remote Control)
Motor Type 4-pole single phase
induction motor
6-pole single phase
induction motor
Input kW 0.36 0.24
Rated
Output
kW 0.25 0.05 x 2
Air-heat exchanger Louvre-fin type Louvre-fin type
Refrigerant Control Capillary tube Capillary tube
Refrigerant oil (Charged) L - SONTEX 200LT (1.2)
Refrigerant (Charged) kg (oz) - R-22 4.2 (148)
Running
Adjustment
Control Switch Wired Remote Control -
Room Temperature Thermostat (Main Body) -
Safety Devices Internal protector for compressor, Internal thermostat
for F.M, Crankcase heater, Drain over-flow switch, High
pressure switch, Current Transformer
Noise Level (Sound Pressure) dB (A) Hi 47 Lo 45 Hi 55
1. Cooling capacities are based on indoor temp. 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.)
and outdoor air temp. 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.) / / / / / /
ELECTRICAL DATA (50Hz)
46
