Panasonic CU-A34BBP8 - Page 32

MODEL / ITEM
CS-A34BD2P/CU-A34BBP8
Condition by JIS B 8616
Volts V 380 400 415
Phase 3N 3N 3N
Input Power kW Cool 3.65 3.65 3.65
Heat 3.40 3.40 3.40
Running Current A Cool 6.5 6.5 6.5
Heat 6.3 6.3 6.3
Starting Current A 39 41 42
Power Factor % Cool 85 81 78
Heat 82 78 75
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power
source
AC, 3N~380V, 400V, 415V 50Hz
3.6 CS-A43BD2P / CU-A43BBP8
ITEM / MODEL
Indoor Unit Outdoor unit
Main Body CS-A43BD2P CU-A43BBP8
Cooling Capacity kW 13.00
(BTU/h) (44,300)
Heating Capacity kW 14.20
(BTU/h) (48,400)
Refrigerant Charge-less m 30
Standard Air Volume for High
Medium and Low Speed
m
3
/min
Hi 50 Hi 82
cfm Hi 1766 2895
External Static Pressure mmAq Hi 10 Me 5 Lo 0 -
Pa Hi 98 Me 49 Lo 0
32
