1-211
1
1-2. Dimensional Data
(A) Indoor Units: S-36PK1E5A, S-45PK1E5A, S-50PK1E5A, S-60PK1E5A, S-71PK1E5A, S-100PK1E5A
FILTER SIZE
(418.5 X 342 X 2) X 2 pcs.
1
2
3
Refrigerant tubing (liquid tube) S36 - S50:
Ćø6.35
(flared) S60 - S100:
Ćø9.52
(flared)
S36 - S50:
Ćø12.7
(flared) S60 - S100:
Ćø15.88
(flared)
Drain hose VP13 (outer dia. Ćø18)
4
Rear panel (PL BACK)
Refrigerant tubing (gas tube)
5
Rear panel fixing holes (Ćø5 holes or 5X13 elongated holes)
6
Piping & coiring holes (Ćø80)
unit: mm
1065
300 230 3
708
60
95 95
231
mc 5mc 5
7.5 cm
450 384
200 140
67
300
415 415
448 440
497568
(Ćø80)
(Ćø80)
158
132
48
48
37
18
4
6
3
2
1
Z
Z view
Nessesary minimum space for a installation
Front view
5
SM830231-02īSingleī꬧å·.indbīīī211SM830231-02īSingleī꬧å·.indbīīī211 2014/09/19īīī13:21:312014/09/19īīī13:21:31
