Panasonic CZ-KPY3A series Service Manual

1-212
1
1-2. Dimensional Data
(A) Indoor Units:
S-36PF1E5A, S-45PF1E5A, S-50PF1E5A, S-60PF1E5A,
S-71PF1E5A, S-100PF1E5A, S-125PF1E5A, S-140PF1E5A
636
33.4
33.4
B
DCD
154
(150)
54
700
30
290
255
15
14023 23
113 65
70 90
26.1
300
186 27
256
172
280
g
h
f
i
c
d
b
a
e
j
Type A B C D E F
36, 45, 50 867 800 450 (Pitch 150 × 3) 71 592 12
60, 71 1,067 1,000 750 (Pitch 150 × 5) 21 792 16
100, 125, 140 1,467 1,400 1,050 (Pitch 150 × 7) 71 1,192 20
Unit: mm
Air intake port side
Air outlet duct side
F-ø3 holes
E (Flange O.D.)
A (Suspension bolt pitch)
a) Refrigerant tubing joint (liquid tube)
b) Refrigerant tubing joint (gas tube)
c) Upper drain port VP25 (O.D. 32 mm)
200 flexible hose supplied
d) Bottom drain port VP25 (O.D. 32 mm)
e) Suspension lug (4 – 12 × 30 mm)
f ) Power supply outlet
g) Fresh air intake port (ø150 mm)
h) Flange for flexible air outlet duct
i ) Electrical component box
j ) Filter
Inspection
access
450 × 450
(Field supply)
SM830231-02Single欧州.indb212SM830231-02Single欧州.indb212 2014/09/1913:21:312014/09/1913:21:31
