Panasonic CZ-KPY3A series Service Manual

1-234
1
1-6. Noise Criterion Curves
(A) Indoor Units:
4-Way Cassette Type
Low
MODEL
SOUND LEVEL
CONDITION
SOURCE
: S-36PU1E5A
: High
Low
30 dB(A)
27 dB(A)
: Under the unit 1.5m
: 220-230-240V, 1 phase, 50Hz
High
Octave Band Level (dB) *0dB = 0.0002 µbar Octave Band Level (dB) *0dB = 0.0002 µbar
Octave Band Level (dB) *0dB = 0.0002 µbar Octave Band Level (dB) *0dB = 0.0002 µbar
Frequency at center of sound pressure band (Hz)
Frequency at center of sound pressure band (Hz)
Frequency at center of sound pressure band (Hz)
Frequency at center of sound pressure band (Hz)
10
20
30
40
50
60
63 125 250 500 1000 2000 4000 8000
NC-60
NC-50
NC-40
NC-30
NC-20
10
20
30
40
50
60
63 125 250 500 1000 2000 4000 8000
NC-40
NC-60
NC-50
NC-30
NC-20
10
20
30
40
50
60
63 125 250 500 1000 2000 4000 8000
NC-40
NC-50
NC-30
NC-20
NC-60
10
20
30
40
50
60
63 125 250 500 1000 2000 4000 8000
NC-40
NC-60
NC-50
NC-30
NC-20
MODEL
SOUND LEVEL
CONDITION
SOURCE
: S-50PU1E5A
: High
Low
32 dB(A)
27 dB(A)
: Under the unit 1.5m
: 220-230-240V, 1 phase, 50Hz
MODEL
SOUND LEVEL
CONDITION
SOURCE
: S-45PU1E5A
: High
Low
31 dB(A)
27 dB(A)
: Under the unit 1.5m
: 220-230-240V, 1 phase, 50Hz
MODEL
SOUND LEVEL
CONDITION
SOURCE
: S-60PU1E5A
: High
Low
36 dB(A)
28 dB(A)
: Under the unit 1.5m
: 220-230-240V, 1 phase, 50Hz
Approximate
minimum
audible limit
for continuous
noise
Approximate
minimum
audible limit
for continuous
noise
Approximate
minimum
audible limit
for continuous
noise
Approximate
minimum
audible limit
for continuous
noise
SM830231-02Single欧州.indb234SM830231-02Single欧州.indb234 2014/09/1913:21:392014/09/1913:21:39
