Panasonic CZ-KPY3A series Service Manual

1-235
1
1-6. Noise Criterion Curves
(A) Indoor Units:
4-Way Cassette Type
REMARKS:
NOTE
1. Value obtained in the actual place where the unit is installed
may be slightly higher than the values shown in this graph
because of the conditions of operation, the structure of the
building, the background noise and other factors.
2. The test results were obtained from an anechoic room.
To evaluate “Noise level” the maximum number of the measured
OCTAVE BAND SOUND PRESSURE LEVEL is used.
Read the number on each BAND CENTER FREQUENCIES
(horizontal axis) ranging from 63 Hz to 8000 Hz and select the
maximum value (vertical axis) among them.
Low
High
Octave Band Level (dB) *0dB = 0.0002 µbar Octave Band Level (dB) *0dB = 0.0002 µbar
Frequency at center of sound pressure band (Hz)
Frequency at center of sound pressure band (Hz)
10
20
30
40
50
60
63 125 250 500 1000 2000 4000 8000
NC-40
NC-50
NC-30
NC-20
NC-60
10
20
30
40
50
60
63 125 250 500 1000 2000 4000 8000
NC-40
NC-60
NC-50
NC-30
NC-20
MODEL
SOUND LEVEL
CONDITION
SOURCE
: S-125PU1E5A
: High
Low
45 dB(A)
33 dB(A)
: Under the unit 1.5m
: 220-230-240V, 1 phase, 50Hz
MODEL
SOUND LEVEL
CONDITION
SOURCE
: S-140PU1E5A
: High
Low
46 dB(A)
34 dB(A)
: Under the unit 1.5m
: 220-230-240V, 1 phase, 50Hz
MODEL
SOUND LEVEL
CONDITION
SOURCE
: S-71PU1E5A
: High
Low
37 dB(A)
28 dB(A)
: Under the unit 1.5m
: 220-230-240V, 1 phase, 50Hz
Octave Band Level (dB) *0dB = 0.0002 µbar Octave Band Level (dB) *0dB = 0.0002 µbar
Frequency at center of sound pressure band (Hz) Frequency at center of sound pressure band (Hz)
10
20
30
40
50
60
63 125 250 500 1000 2000 4000 8000
NC-60
NC-50
NC-40
NC-30
NC-20
10
20
30
40
50
60
63 125 250 500 1000 2000 4000 8000
NC-40
NC-60
NC-50
NC-30
NC-20
MODEL
SOUND LEVEL
CONDITION
SOURCE
: S-100PU1E5A
: High
Low
44 dB(A)
32 dB(A)
: Under the unit 1.5m
: 220-230-240V, 1 phase, 50Hz
Approximate
minimum
audible limit
for continuous
noise
Approximate
minimum
audible limit
for continuous
noise
Approximate
minimum
audible limit
for continuous
noise
Approximate
minimum
audible limit
for continuous
noise
SM830231-02Single欧州.indb235SM830231-02Single欧州.indb235 2014/09/1913:21:392014/09/1913:21:39
