Panasonic CZ-KPY3A series Service Manual

1
1-407
Outdoor air intake temp(°C D.B.)
Model
Power
Source
Ambient
Return
Air
25°C 30°C 35°C 40°C 46°C
DB WB TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT
S-36PU1E5A×2
U-71PE1E5A
(U-71PE1E8A)
220V
230V
240V
50Hz
1 phase
(3 phase)
23
16 8.3 7.0 2.30 8.1 7.1 2.46 7.8 6.9 2.64 7.4 6.7 2.62 6.5 6.4 2.24
19 8.7 5.1 2.38 8.5 5.0 2.54 8.2 4.9 2.70 7.7 4.7 2.65 6.7 4.4 2.27
22 9.3 3.1 2.48 8.9 3.0 2.63 8.6 2.9 2.78 8.0 2.7 2.67 7.0 2.5 2.30
25
16 8.3 8.3 2.30 8.1 8.1 2.46 7.8 7.8 2.64 7.4 7.4 2.62 6.5 6.5 2.24
19 8.7 6.3 2.38 8.5 6.2 2.54 8.2 6.1 2.70 7.7 5.9 2.65 6.7 5.5 2.27
22 9.3 4.3 2.48 8.9 4.2 2.63 8.6 4.1 2.78 8.0 3.9 2.67 7.0 3.6 2.30
27
16 8.3 8.3 2.30 8.1 8.1 2.46 7.8 7.8 2.64 7.4 7.4 2.62 6.5 6.5 2.24
19 8.7 7.4 2.38 8.5 7.5 2.54 8.2 7.3 2.70 7.7 7.0 2.65 6.7 6.7 2.27
22 9.3 5.6 2.48 8.9 5.3 2.63 8.6 5.2 2.78 8.0 5.1 2.67 7.0 4.8 2.30
29
16 8.3 8.3 2.30 8.1 8.1 2.46 7.8 7.8 2.64 7.4 7.4 2.62 6.5 6.5 2.24
19 8.7 8.7 2.38 8.5 8.5 2.54 8.2 8.2 2.70 7.7 7.7 2.65 6.7 6.7 2.27
22 9.3 6.7 2.48 8.9 6.6 2.63 8.6 6.5 2.78 8.0 6.3 2.67 7.0 6.0 2.30
32
16 8.3 8.3 2.30 8.1 8.1 2.46 7.8 7.8 2.64 7.4 7.4 2.62 6.5 6.5 2.24
19 8.7 8.7 2.38 8.5 8.5 2.54 8.2 8.2 2.70 7.7 7.7 2.65 6.7 6.7 2.27
22 9.3 6.7 2.48 8.9 6.6 2.63 8.6 6.5 2.78 8.0 6.3 2.67 7.0 6.0 2.30
S-36PU1E5A×3
U-100PE1E5A
(U-100PE1E8A)
220V
230V
240V
50Hz
1 phase
(3 phase)
23
16 11.4 10.2 3.00 11.4 10.2 3.23 10.9 9.9 3.43 10.2 9.8 3.57 7.4 7.4 2.92
19 12.1 7.4 3.13 12.1 7.4 3.36 11.7 7.1 3.58 10.9 6.9 3.72 7.9 5.7 3.04
22 13.3 4.5 3.24 13.3 4.5 3.48 12.8 4.4 3.70 11.9 4.0 3.85 8.7 3.0 3.15
25
16 11.8 11.8 3.05 11.8 11.8 3.28 11.3 11.3 3.49 10.5 10.5 3.63 7.7 7.7 2.97
19 12.6 9.5 3.18 12.6 9.5 3.42 12.1 9.2 3.64 11.2 9.1 3.79 8.2 7.7 3.09
22 13.8 6.6 3.29 13.8 6.6 3.54 13.2 6.4 3.77 12.3 6.2 3.92 9.0 4.9 3.20
27
16 12.2 12.2 3.10 12.2 12.2 3.33 11.7 11.7 3.55 10.9 10.9 3.69 8.0 8.0 3.02
19 13.0 11.9 3.24 13.0 11.9 3.48 12.5 11.5 3.70 11.6 11.3 3.85 8.5 8.5 3.15
22 14.2 8.9 3.35 14.2 8.9 3.60 13.7 8.6 3.83 12.7 8.4 3.98 9.3 7.1 3.25
29
16 12.4 12.4 3.11 12.4 12.4 3.34 11.9 11.9 3.56 11.0 11.0 3.70 8.1 8.1 3.02
19 13.2 13.2 3.25 13.2 13.2 3.49 12.7 12.7 3.71 11.8 11.8 3.86 8.6 8.6 3.15
22 14.5 11.1 3.36 14.5 11.1 3.61 13.9 10.7 3.84 12.9 10.6 3.99 9.5 9.1 3.26
32
16 12.5 12.5 3.12 12.5 12.5 3.35 12.1 12.1 3.56 11.2 11.2 3.71 8.2 8.2 3.03
19 13.4 13.4 3.25 13.4 13.4 3.50 12.9 12.9 3.72 12.0 12.0 3.87 8.8 8.8 3.16
22 14.7 11.3 3.37 14.7 11.3 3.62 14.1 10.9 3.85 13.1 10.8 4.00 9.6 9.2 3.27
S-50PU1E5A×2
U-100PE1E5A
(U-100PE1E8A)
220V
230V
240V
50Hz
1 phase
(3 phase)
23
16 11.4 9.1 3.00 11.4 9.1 3.23 10.9 8.7 3.43 10.2 8.5 3.57 7.4 7.3 2.92
19 12.1 6.8 3.13 12.1 6.8 3.36 11.7 6.6 3.58 10.9 6.3 3.72 7.9 5.1 3.04
22 13.3 4.5 3.24 13.3 4.5 3.48 12.8 4.4 3.70 11.9 4.0 3.85 8.7 3.0 3.15
25
16 11.8 10.7 3.05 11.8 10.7 3.28 11.3 10.4 3.49 10.5 10.3 3.63 7.7 7.7 2.97
19 12.6 8.4 3.18 12.6 8.4 3.42 12.1 8.2 3.64 11.2 8.0 3.79 8.2 6.6 3.09
22 13.8 6.2 3.29 13.8 6.2 3.54 13.2 5.9 3.77 12.3 5.7 3.92 9.0 4.4 3.20
27
16 12.2 12.2 3.10 12.2 12.2 3.33 11.7 11.7 3.55 10.9 10.9 3.69 8.0 8.0 3.02
19 13.0 10.2 3.24 13.0 10.2 3.48 12.5 9.9 3.70 11.6 9.7 3.85 8.5 8.4 3.15
22 14.2 8.0 3.35 14.2 8.0 3.60 13.7 7.7 3.83 12.7 7.4 3.98 9.3 6.1 3.25
29
16 12.4 12.4 3.11 12.4 12.4 3.34 11.9 11.9 3.56 11.0 11.0 3.70 8.1 8.1 3.02
19 13.2 11.9 3.25 13.2 11.9 3.49 12.7 11.6 3.71 11.8 11.4 3.86 8.6 8.6 3.15
22 14.5 9.6 3.36 14.5 9.6 3.61 13.9 9.4 3.84 12.9 9.1 3.99 9.5 7.7 3.26
32
16 12.5 12.5 3.12 12.5 12.5 3.35 12.1 12.1 3.56 11.2 11.2 3.71 8.2 8.2 3.03
19 13.4 12.1 3.25 13.4 12.1 3.50 12.9 11.7 3.72 12.0 11.6 3.87 8.8 8.8 3.16
22 14.7 9.8 3.37 14.7 9.8 3.62 14.1 9.5 3.85 13.1 9.2 4.00 9.6 7.8 3.27
S-36PU1E5A×4
U-125PE1E5A
(U-125PE1E8A)
220V
230V
240V
50Hz
1 phase
(3 phase)
23
16 12.7 11.8 3.73 12.7 11.9 4.01 12.2 11.5 4.27 11.4 11.4 4.44 8.3 8.3 3.63
19 13.6 8.4 3.89 13.6 8.5 4.18 13.1 8.2 4.45 12.2 8.0 4.63 8.9 6.7 3.78
22 14.9 5.1 4.03 14.9 5.0 4.33 14.3 4.9 4.60 13.3 4.6 4.79 9.7 3.4 3.91
25
16 13.2 13.2 3.80 13.2 13.2 4.08 12.7 12.7 4.34 11.8 11.8 4.51 8.6 8.6 3.69
19 14.1 11.0 3.96 14.1 11.1 4.25 13.5 10.7 4.52 12.6 10.5 4.71 9.2 9.1 3.85
22 15.4 7.6 4.10 15.4 7.6 4.40 14.8 7.3 4.68 13.8 7.1 4.87 10.1 5.8 3.98
27
16 13.6 13.6 3.86 13.6 13.6 4.15 13.1 13.1 4.41 12.2 12.2 4.59 8.9 8.9 3.75
19 14.6 13.7 4.03 14.6 13.8 4.32 14.0 13.3 4.60 13.0 13.0 4.78 9.5 9.5 3.91
22 16.0 10.3 4.16 16.0 10.3 4.47 15.3 9.9 4.76 14.3 9.7 4.95 10.4 8.2 4.05
29
16 13.8 13.8 3.87 13.8 13.8 4.16 13.3 13.3 4.42 12.4 12.4 4.60 9.0 9.0 3.76
19 14.8 14.8 4.03 14.8 14.8 4.33 14.2 14.2 4.61 13.2 13.2 4.80 9.7 9.7 3.92
22 16.2 12.8 4.17 16.2 12.9 4.48 15.6 12.5 4.77 14.5 12.4 4.96 10.6 10.6 4.06
32
16 14.0 14.0 3.88 14.0 14.0 4.17 13.5 13.5 4.43 12.6 12.6 4.61 9.2 9.2 3.77
19 15.0 15.0 4.04 15.0 15.0 4.35 14.4 14.4 4.62 13.4 13.4 4.81 9.8 9.8 3.93
22 16.4 13.0 4.18 16.4 13.1 4.50 15.8 12.7 4.78 14.7 12.6 4.97 10.7 10.7 4.07
S-45PU1E5A×3
U-125PE1E5A
(U-125PE1E8A)
220V
230V
240V
50Hz
1 phase
(3 phase)
23
16 12.7 10.5 3.73 12.7 10.6 4.01 12.2 10.3 4.27 11.4 10.0 4.44 8.3 8.3 3.63
19 13.6 7.8 3.89 13.6 7.8 4.18 13.1 7.5 4.45 12.2 7.3 4.63 8.9 6.0 3.78
22 14.9 5.0 4.03 14.9 5.0 4.33 14.3 4.8 4.60 13.3 4.5 4.79 9.7 3.3 3.91
25
16 13.2 12.8 3.80 13.2 12.9 4.08 12.7 12.5 4.34 11.8 11.8 4.51 8.6 8.6 3.69
19 14.1 9.9 3.96 14.1 10.0 4.25 13.5 9.6 4.52 12.6 9.4 4.71 9.2 8.0 3.85
22 15.4 7.1 4.10 15.4 7.1 4.40 14.8 6.9 4.68 13.8 6.6 4.87 10.1 5.2 3.98
27
16 13.6 13.6 3.86 13.6 13.6 4.15 13.1 13.1 4.41 12.2 12.2 4.59 8.9 8.9 3.75
19 14.6 12.1 4.03 14.6 12.2 4.32 14.0 11.8 4.60 13.0 11.5 4.78 9.5 9.5 3.91
22 16.0 9.3 4.16 16.0 9.4 4.47 15.3 9.0 4.76 14.3 8.8 4.95 10.4 7.3 4.05
29
16 13.8 13.8 3.87 13.8 13.8 4.16 13.3 13.3 4.42 12.4 12.4 4.60 9.0 9.0 3.76
19 14.8 14.2 4.03 14.8 14.3 4.33 14.2 13.9 4.61 13.2 13.2 4.80 9.7 9.7 3.92
22 16.2 11.5 4.17 16.2 11.4 4.48 15.6 11.1 4.77 14.5 10.8 4.96 10.6 9.3 4.06
32
16 14.0 14.0 3.88 14.0 14.0 4.17 13.5 13.5 4.43 12.6 12.6 4.61 9.2 9.2 3.77
19 15.0 14.4 4.04 15.0 14.5 4.35 14.4 14.1 4.62 13.4 13.4 4.81 9.8 9.8 3.93
22 16.4 11.5 4.18 16.4 11.6 4.50 15.8 11.2 4.78 14.7 11.0 4.97 10.7 9.4 4.07
1-13. Capacity Table
1. Cooling Capacity Performance Data
•
Combination of Multiple Unit
4-Way Cassette Type
TC :Cooling Capacity
SHC :Sensible Heat Capacity
IPT :Cooling Power Consumption
unit : kW
