Panasonic CZ-KPY3A series Service Manual

1
1-446
1-13. Capacity Table
2. Heating Capacity Performance Data
•
Combination of Multiple Unit
Wall Mounted Type
TC :Cooling Capacity
IPT :Cooling Power Consumption
unit : kW
Outdoor air intake temp(°C W.B.)
Model
Power
Source
Ambient
Return
Air
-5°C 0°C 6°C 10°C 15°C
DB TC IPT TC IPT TC IPT TC IPT TC IPT
S-36PK1E5A×2
U-71PE1E5A
(U-71PE1E8A)
220V
230V
240V
50Hz
1 phase
(3 phase)
16 8.2 2.88 8.5 2.90 9.7 2.86 9.9 2.67 9.9 2.47
20 7.8 2.96 8.1 2.98 9.0 2.90 9.0 2.72 9.0 2.49
24 7.4 3.05 7.7 3.07 8.1 2.96 8.1 2.78 8.1 2.55
S-36PK1E5A×3
U-100PE1E5A
(U-100PE1E8A)
220V
230V
240V
50Hz
1 phase
(3 phase)
16 15.1 4.97 15.1 4.77 15.1 4.16 15.1 3.66 15.1 3.10
20 14.0 5.26 14.0 5.05 14.0 4.40 14.0 3.87 14.0 3.28
24 13.1 5.34 13.1 5.13 13.1 4.47 13.1 3.94 13.1 3.33
S-50PK1E5A×2
U-100PE1E5A
(U-100PE1E8A)
220V
230V
240V
50Hz
1 phase
(3 phase)
16 15.1 4.97 15.1 4.77 15.1 4.16 15.1 3.66 15.1 3.10
20 14.0 5.26 14.0 5.05 14.0 4.40 14.0 3.87 14.0 3.28
24 13.1 5.34 13.1 5.13 13.1 4.47 13.1 3.94 13.1 3.33
S-36PK1E5A×4
U-125PE1E5A
(U-125PE1E8A)
220V
230V
240V
50Hz
1 phase
(3 phase)
16 16.7 5.52 17.2 5.43 17.3 4.91 17.3 4.33 17.3 3.66
20 15.5 5.84 15.9 5.74 16.0 5.20 16.0 4.58 16.0 3.87
24 14.5 5.93 14.9 5.84 15.0 5.28 15.0 4.65 15.0 3.94
S-45PK1E5A×3
U-125PE1E5A
(U-125PE1E8A)
220V
230V
240V
50Hz
1 phase
(3 phase)
16 16.7 5.52 17.2 5.43 17.3 4.91 17.3 4.33 17.3 3.66
20 15.5 5.84 15.9 5.74 16.0 5.20 16.0 4.58 16.0 3.87
24 14.5 5.93 14.9 5.84 15.0 5.28 15.0 4.65 15.0 3.94
S-60PK1E5A×2
U-125PE1E5A
(U-125PE1E8A)
220V
230V
240V
50Hz
1 phase
(3 phase)
16 16.7 5.52 17.2 5.43 17.3 4.91 17.3 4.33 17.3 3.66
20 15.5 5.84 15.9 5.74 16.0 5.20 16.0 4.58 16.0 3.87
24 14.5 5.93 14.9 5.84 15.0 5.28 15.0 4.65 15.0 3.94
S-50PK1E5A×3
U-140PE1E5A
(U-140PE1E8A)
220V
230V
240V
50Hz
1 phase
(3 phase)
16 18.1 5.72 19.2 5.69 19.4 5.57 19.4 4.91 19.4 4.15
20 16.7 6.05 17.8 6.02 18.0 5.90 18.0 5.19 18.0 4.40
24 15.7 6.15 16.7 6.12 16.9 6.00 16.9 5.28 16.9 4.47
S-71PK1E5A×2
U-140PE1E5A
(U-140PE1E8A)
220V
230V
240V
50Hz
1 phase
(3 phase)
16 18.1 5.72 19.2 5.69 19.4 5.57 19.4 4.91 19.4 4.15
20 16.7 6.05 17.8 6.02 18.0 5.90 18.0 5.19 18.0 4.40
24 15.7 6.15 16.7 6.12 16.9 6.00 16.9 5.28 16.9 4.47
SM830231-02Single欧州.indb446SM830231-02Single欧州.indb446 2014/09/1913:22:232014/09/1913:22:23
