4-23
4
4-13. Outdoor Unit Control PCB
4-13-1. Single-Phase Unit
CR-PCB
CR-50PE1E5:Up side (U-50PE1E5)
D008(LED2)
D007 (LED1)
S003
(R.C.ADD)
TERMINAL
S002
(R.C.ADD)
C-CHK(CN033)
(COOL_CHECK)
A.ADD(CN041)
MODE(CN031)
PUMP DOWN(CN042)
JP001
JP007
RC plug(RC-P)
POWER LED (D225)
EEPROM memory IC
(IC006)
LED for EEPROM
memory IC (D014)
HIC
(CN01)
