Getting started
- 9 -
1 Disc tray (> 14)
2 USB port (> 14)
3 POWER LED
The LED lights when the unit is turned on,
and flashes when error occurs. (> 31)
4 Remote control signal sensor
Distance: Within approx. 7 m (23 feet)
Angle: Approx. 20e up and down, 30e left and
right
5 Open or close the disc tray (> 14)
6
[BDT280] Stop (> 16)
7
[BDT280] Start play (> 16)
8 Standby/on switch (Í/I) (> 12)
Press to switch the unit from on to standby
mode or vice versa. In standby mode, the unit
still consumes a small amount of power.
Rear panel terminals (> 10, 11)
