Panasonic DP-6030 - Page 227

227
JAN 2006
Ver. 5.2
DP-3510/3520/3530/4510/4520/4530/6010/6020/6030
5.1.5. F6 Mode: Adjust Parameters (For Copier)
Set the machine to Service Mode and press "6" key on the Keypad.
↓
Press the "START" key.
↓
Select the desired code number on the Touch Panel display.
↓
If you wish to select another code number, scroll the menu with the arrow buttons.
↓
Select the desired function on the Touch Panel display and touch the "OK" button.
↓
When the "C (CLEAR)" key is touched, the selected code input will not be accepted.
↓
Press "FUNCTION" and "C (CLEAR)" keys simultaneously to exit the service mode.
↓
Reboot the machine after setting the parameter(s) to activate the setting(s).
Note:
The Factory Setting is different in each model.
F6 Mode
No. Item Remarks
Setting
Range
00 Adjust 100% read (s/s) Adjustment of ratio for vertical position when
scan is made.
-9 - +9 0.1%
01 Adjust read mag. (l/t) Adjustment of ratio for parallel position when
scan is made.
-9 - +9 0.1%
02 100% selection Adjustment from 99.1% to 100.9% -9 - +9 0.1%
03 Original registration Adjustment of platen original registration
detection timing.
-30 - +30
0.2mm
04 Printer registration Delay time is adjusted from registration roller
clutch ON.
-50 - +50
0.5mm
05 Main motor speed Adjustment of Main Motor speed. -10 - +10
0.1%
06 Polygon motor speed Adjustment Polygon Motor speed. -99 - +99
0.1%
07 Registration void Registration void should be adjusted. 0 - +99
0.5mm
08 Trail edge read timing Adjustment of trail edge void. -9 - 0
0.5mm
09 Trail edge print timing Adjustment of trail edge void. -9 - +15
0.5mm
10 Side adjust (Bypass) Adjustment of LSU side-side (Sheet Bypass). -8 - +7
0.5mm
11 Side adjust (Tray 1) Adjustment of LSU side-side (1st Tray). -8 - +7
0.5mm
12 Side adjust (Tray 2) Adjustment of LSU side-side (2nd Tray). -8 - +7
0.5mm
13 Side adjust (Tray 3) Adjustment of LSU side-side (3rd Tray). -8 - +7
0.5mm
