Model No. : EY4542 Parts List
Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
1 WEY3500K0356 SPRING PIN 1 (φ6-45)
2 WEY4542S3427 SHOE 1
3 WEYT502K6487 ADJUSTING BOLT 1
4 WEY3503K0196 SPRING 1 (φ7.6*15)
5 WEY3530S6387 WASHER 1 (φ5)
6 WEY3503K0896 DEPTH ADJUSTING NUT 1
7 WEY3530K6256 FLANGE SOCKET 1 (M5*12)
8 WEY3501K1176 OUTER WASHER 1
9 WEY3503L1166 INNER WASHER 1
10 WEY3503L0426 STOP RING 1
11 WEY3530K1196 LOWER GUARD 1
12 WEY3503S9386 TAPPING SCREW 1 (4*40)
13 WEY3510K0397 LOWER GUARD STOPPER 1
14 WEY4542Y6457 WASHER 1 (φ4)
15 WEY3503K9037 TAPPING SCREW 1 (K3-12)
16 WEY3503L0926 SPRING 1 (φ5.45*49)
17 WEY4542S6457 WASHER 1 (φ3)
18 WEY4542L6537 SQUARE SCREW 1 (M5)
19 WEY4542K3107 SAFETY COVER A 1
20 WEY4542K3128 SAFETY COVER B 1
21 WEY4542K3079 HOUSING AB SET 1 (for EUROPE)
21 WEY4542K3070 HOUSING AB SET 1 (for OCEANIA)
22 WEY4542X3117 TRANSPARENT COVER 1
23 WEY4542X3047 DUST CASE 1
24 WEY4542X3147 FRONT COVER 1
25 WEY4542L1458 GEAR BOX ASSEMBLY 1
26 WEY3503K6206 FREARSON SCREW 8 (K4*20)
27 WEY3503L0846 THRUST PLATE 2
28 WEY3530L1437 MID GEAR 1
29 WEY4542L4057 OUTPUT GEAR 1
30 WEY4542L0387 BEARING 1
31 WEY3530L0976 O RING 1
32 WEY4542L6067 SCREW 2 (K5*8), (2PCS/PK)
33 WEY4542L1008 MOTOR ASSEMBLY 1
34 WEY4542H0367 SPINDLE LOCK BUTTON 1
35 WEY3500K0196 LOCK BUTTON SPRING 1 (15.4*37)
36 WEY4542H3237 OFF LOCK LEVER 1
37 WEYT502L0917 OFF LOCK SPRING 1
38 WEY4542L2007 SWITCH 1
39 WEY4542L2107 MAIN PCB ASSEMBLY 1
40 WEY4542L2117 LED ASSEMBLY 1
41 WEY4542K9447 TAPPING SCREW 1 (2*5)
42 WEY7440K9038 TAPPING SCREW 13 (K3*20)
