5
Bahagian-Bahagian Yang Dibekalkan / Supplied Parts /
ᛑᣘ᱕ၯ
OFF/ON
YURAGI
SPEED
1
1
2
3
36h
4
5
Ceiling Fan
CANCEL
OFF
TIMER
SLEEP MODE
Bahagian-bahagian / Parts /
᱕ၯ
Kuantiti /
Piece(s) /
ၯ
1.
Pemasangan Motor / Motor Assembly /
ᜅῈᡊၯ
1
2.
Sengkuap / Canopy /
᮳ᵸ
2
3. Set
Pemasangan Bilah Kipas / Blade
Assembly Set /
ᖱℶᡊၯ
4
4.
Penutup Hiasan / Decoration Cap /
ᯮᱢᤦ
1
5.
Bateri AA, R6P , R6, LR6 / Batteries AA,
R6P , R6, LR6 /
᱓კ
AA, R6P , R6, LR6
2
6.
Alat Kawalan Jauh / Remote Control
Unit /
ᶵញᾊ
1
7.
Set Komponen (8 biji Skru) / Part Set
(8 pcs Screws) /
᱕ၯᡊ!ළ
8
!ጃ⅛ᨃෆ
1
8.
Set Pemegang Alat Kawalan Jauh /
Remocon Holder Set /
ᶵញᾊቦᾊᡊၯ
1
1
2
3
4
56 7 8
Bagaimana Memasang / How to Install /
ႫᄌႲᯮ
1
1
Pasang Skru “Hanger Supporter” dan ketatkan semua Skru, Bolt, Nat, Sesendal
Pegas dan Cemat Baji dengan rapi.
Remove the supplied Bolt, Nut, Spring Washer, Washer, Cotter Pin and Pulley
from the Hanger Plate Assembly.
ᝈᛑᣘፇ⅛ᗫඪ⅛ᤦඪḮ⇳ᲔᜤඪᲔᜤඪ᪈ཧὃᭌἰᝫႌዾᡊၯዞᛞණ
Bolt / Bolt /
⅛ᗫ
Takal / Pulley /
ᭌἰ
Cermat Baji / Cotter Pin /
᪈ཧὃ
Nat / Nut /
⅛ᤦ
Sesendal Pegas / Spring
Washer /
Ḯ⇳Ეᜤ
Sesendal / Washer /
Ეᜤ
2
2
Pasang Takal pada
cangkuk.
Place the Pulley onto the
Hook.
ᝈᭌἰዡႝ᱁མ!ණ
Siling / Ceiling /
ྰ፮ዾ
Cangkuk /
Hook /
᱁
Cangkuk /
Hook /
᱁
Atau / Or /
ኾ
Takal /
Pulley /
ᭌἰ
3
3
Setelah selesai memasang Unit Motor pada Cangkuk, pasang dan kencangkan
kembali Bolt, Sesendal, Sesendal Pegas, Nat dan Pengunci.
(Kilas pengetatan untuk rujukan: 1200-1500N.cm)
After hanging the Motor Assembly to the Hook, re-fi x and fi rmly tighten the
previous Bolt, Washer, Spring Washer, Nut and slot the Cotter Pin
( Tightening torque for reference: 1200-1500N.cm)
ᝈᜅῈᡊၯពམ᱁႕ඩᔏᬛᯮམ∯ᵏ྆Ꮁዞᛞፇ⅛ᗫඪ!Ეᜤඪ!Ḯ⇳Ეᜤඪ
⅛ᤦඩᦻᐋᥐཋ᪈ཧὃණළᆗᵏ∥ᩥᜭද!
1200-1500N.cm
ෆ
AMARAN / WARNING /
⌴ᅁ
Pengunci harus masuk ke dalam Bolt dan dilekukkan.
Dapat menyebabkan luka jika unit terjatuh.
Cotter Pin must fi x into Bolt and bent.Can cause injury if ceiling fan drops.
᪈ཧὃီ᪠ᥐཋ⅛ᗫᦻ႕ᆟ⎱ණᓟႌᖱបᯋᬤᾚᓖණ
Sesendal /
Washer /
Ეᜤ
Bolt /
Bolt /
⅛ᗫ
Cermat Baji /
Cotter Pin /
᪈ཧὃ
Nat / Nut /
⅛ᤦ
Cangkuk /
Hook /
᱁
Sesendal Pegas /
Spring Washer /
Ḯ⇳Ეᜤ
4
4
Lepaskan Kawat Keselamatan dari Gantungan.
Remove the Safety Wire Screw from the Hanger Plate.
ᝈ⁶ị⅛ᨃႌዾᡊၯዞණ
Sekrup Kawat Keselamatan/
Safety Wire Screw /
⁶ị⅛ᨃ
Gantungan /
Hanger Plate /
ႌዾᡊၯ
AMARAN / WARNING /
⌴ᅁ
Pastikan Cangkuk dapat bertahan 10 kali lebih
berat dari berat unit kipas.
Ensure Hook can sustain more than 10 times
the Ceiling Fan weight.
Ẫ᱁ဇዃᩢᰮႌᖱፇ21ᔣᔏ᩼ණ
Pemasangan Gantungan /
Hanger Plate Assembly /
ႌዾᡊၯ
