REPLACEMENT MECHANICAL PARTS LIST (Power Unit and Circuit Board)
Ref. No. Part No. Part Name & Description Remarks
1 PBJEA0090Z Fan
2 PBAPX012065A POWER Board
(RTL)
3 PJJRB0615Z AC Inlet Cable
4 PJJRB0608Z Power Unit Relay Cable (CN861-CN802)
5 PBMCX0086Y Power Box Assembly
6 PJHXB0002Z POWER Board Sheet (ISO Code:PVC)
7 PJJRB0616Z AC Switch Cable
8 PBAPX062065A MOTHER Board (RTL)
9 PBAPX022065A DC-DC CONVERTER Board (RTL)
10 PJJRB0606Z Cable (CN2003-CN381)
11 PJJRB0603Z Cable (CN862-CN2009)
12 PBMCA0091Z Mechacon Box (Rear)
13 PBMCX0089Y Mechacon Box
14 SJ-W2F4A03BB AC Switch
15 PBMXA0038Z MOTHER Board Sheet (ISO Code:PVC)
18 GR-180S Guide Rail (ISO Code:PC)
19 EDS-17L Edge Saddle
20 EDS-0607M Edge Saddle
21 PBMCA0087Z-J Mechacon Box Cover
22 PBAPX03265A MAIN CONTROL Board (RTL)
23 PBAPX05265A SCSI Board (RTL)
24 PJMDB0012Z-J SCSI Board Cover
25 A-46-5 Handle
26 PBHMA0128Z Plate
27 PBHMA0135Z Plate
28 PBHMA0134Z-J Plate
29 PBJEA0550Z Cable (CN2005-CN506)
30 PBJEA0549Z Cable (CN2006-CN501)
32 PBJEA0551Y CIS (F) 1 Cable
34 PBJEA0553Y CIS (B) 1 Cable
40 LWS1SV0BK Locking Wire Saddle
41 LWS-1S Locking Wire Saddle
