13
Loading Documents on the ADF
ADF (Auto Document Feeder) enables multiple sheet scanning.
Acceptable documents
Document size:
Paper weight: 31 g/m
2
–127 g/m
2
(8.3 lb.–34 lb.)
Maximum number of sheets (new paper) loadable on the hopper
• The number of sheets depends on the paper quality. If a paper jam or double feed occurs, reduce the number of
sheets of the document loaded on the hopper.
Notice
• Use "Thin Paper Feeding Mode" when scanning a document less than 40 g/m
2
(10.6 lb.). For details about
"Thin Paper Feeding Mode", refer to the Image Capture Plus, TWAIN, or ISIS help.
Recommendable paper: Plain paper
Documents must also meet the following conditions
Paper weight
80 g/m
2
(21 lb.) Less than 40 g/m
2
(10.6 lb.)
Number of sheets 200 150
Curl
Folding
70 mm~432 mm (2.75 in.~17 in.)
48 mm~302 mm (1.9 in.~11.9 in.)
Feeding direction
Less than
5 mm
(0.2 in.)
Less than
5 mm
(0.2 in.)
Feeding direction
To Next Page
