Panasonic KX-A143EXC - Page 40

Items
Adjustment
Point
Procedure*
Check
(I) Modulatoin
Check and
Adjustment
ANT Follow steps 1 to 3 of (H) above.
4. Confirm that the B-Field Modulation is 340kHz/div ~ 402kHz/
div using data type Fig31.
5. Adjust the B-Field Modulation if required. (Execute the
command "readmod" and "wrtmod xx", where xx is the value.)
IC2,IC3,L1,
C75,C69,C48,
C67,C76,C57,
DA1,R66,R67,
R78,R79,C54,
(J) Frequency Offset
Confirmation
- Follow steps 1 to 3 of (H) above.
4. Confirm that the frequency offset is -50kHz ~ +50kHz.
IC2,IC3,L1,
C75,C69,C48,
C67,C76,C57,
DA1,R66,R67,
R78,R79,C54,
40
