KX-NT300 series (except KX-NT321) and KX-NT500 series (except KX-NT551)
PBX IP Address
ENTER ENTER
Select "PBX". Select "PBX IP Address". Select "Primary PBX".
ENTER ENTER
To enter the IP address of the PBX
Press
"SETUP"
when it is displayed.
SETUP
To start programming
Supply power to the IP-PT.
To enter the IP address of the Secondary PBX
*2
PBX IP Address
Select "Secondary PBX".
ENTER ENTER
To the VLAN settings
Press
"STORE".
To end programming
To set VLAN parameters
OR
The IP-PT will reboot
and can then be
registered to the PBX.
STORE
Return to the
Menu screen.
*1
*1
For KX-NT300 series: Software version 2.00 or later only
For KX-NT500 series: Software version 1.00 or later only
*2
Optional for KX-NT300 series (Software version 2.00 or later only) and KX-NT500 series (Software version 1.00 or later only)
Note
The illustrations may differ from the buttons on your telephone.
184 Installation Manual Document Version 2016-03
5.7.1 Assigning IP Addressing Information
