Panasonic KX-NS Series Installation Manual

KX-NT553/KX-NT556
Select "LLDP".
ENTER
ENTER
VLAN ID
*1
ENTER
VLAN Priority
*1*2
1
Press "STORE".
STORE
To set the VLAN ID for the primary port
To set the VLAN ID for the secondary port
To end programming
0–7
0–4094Select "Primary port".
ENTER
ENTER ENTER
0–4094
Select
"Secondary port".
Select "VLAN Priority".
ENTER
Return to the
LLDP setting screen.
ENTER
Select
"VLAN Priority".
ENTER
Return to the
Menu screen.
Select "Enable" for
LLDP setting.
Select "VLAN ID".
Select "VLAN ID".
0–7
After assigning
the IP addresses
Select "QoS".
ENTER
The IP-PT will reboot
and can then be
registered to the PBX.
VLAN ID
*1
VLAN Priority
*1*2
To set the Interval time for LLDP
ENTER
ENTER
Select
"LLDP (Secondary)".
Return to the
LLDP setting screen.
ENTER
Select "LLDP (Interval)".
INTERVAL
1–3600
*1
The VLAN ID and the VLAN priority are set automatically for the primary port; these are reference only. However, the VLAN ID and
the VLAN priority for secondary port must be set manually.
*2
The VLAN priority of the primary port must be set higher than the priority of the secondary port. The larger the number, the higher
the priority.
208 Installation Manual Document Version 2016-03
5.7.3 Setting LLDP Parameters
