Panasonic KX-NS Series Installation Manual

KX-NT551
VLAN Priority
*1*2
0–7
After assigning
the IP addresses
Select "QoS". Press SP-PHONE. Select "LLDP". Press SP-PHONE.
Select "Enable"
for LLDP setting.
Press SP-PHONE.
To end programming
Press STORE.
Press HOLD three
times to return to the
Menu screen.
The IP-PT will reboot
and can then be
registered to the PBX.
0–7
Select "Priority".
Press SP-PHONE.
VLAN Priority
*1*2
Press SP-PHONE.
To set the VLAN ID for the secondary port
Select "LLDP (Secondary)". Press SP-PHONE. Select "VLAN ID".
Press SP-PHONE.
VLAN ID
*1
0–4094
VLAN ID
*1
To set the VLAN ID for the primary port
Select "LLDP (Primary)". Press SP-PHONE.
Select "VLAN ID".
Select "Priority".
0–4094
To set the Interval time for LLDP
Select "LLDP (Secondary)".
Press SP-PHONE. Select "LLDP (Interval)".
Press SP-PHONE.
INTERVAL
1–3600
*1
The VLAN ID and the VLAN priority are set automatically for the primary port; these are reference only. However, the VLAN ID and
the VLAN priority for secondary port must be set manually.
*2
The VLAN priority of the primary port must be set higher than the priority of the secondary port. The larger the number, the higher
the priority.
Document Version 2016-03 Installation Manual 209
