Panasonic KX-NS Series Installation Manual

Application LAN Side Port Number WAN Side Port Number
FTP The port number used for the FTP
protocol. This is used for software
updates.
NAT - FTP Server Port No.
(Use the same value as in step 5 of
"Programming the PBX with Built-in
Media Relay Gateway
".)
*1
The port number ranges must be within the range of RTP/RTCP for NAT traversal (16000–18047).
Up to 2 IP addresses can be assigned to the PBX’s optional DSP cards.
For the IP-CS (KX-NS0154 only):
Application LAN Side Port Number WAN Side Port Number
PTAP Signaling (PTAP) UDP Port No.
(Server)
(refer to PC Programming Manual
"9.17 PBX Configuration—[1-1]
Configuration
—Slot—Card
Property—V-IPCS")
Signaling (PTAP) UDP Port No.
(Server)
(refer to PC Programming Manual
"9.17 PBX Configuration—[1-1]
Configuration—Slot—Card
Property—V-IPCS")
MGCP Signaling (MGCP) UDP Port No.
(Server)
(refer to PC Programming Manual
"9.17 PBX Configuration—[1-1]
Configuration
—Slot—Card
Property—V-IPCS")
NAT - MGCP Server Port No. for
IP-CS
(Use the same value as in step 5 of
"Programming the PBX with Built-in
Media Relay Gateway".)
RTP (UDP) Start/End RTP (UDP) Port No.
(Use port numbers that are in the
range
of the RTP ports that the PBX
uses.)
*1
Start/End RTP (UDP) Port No.
(Use port numbers that are in the
range of the RTP ports that the PBX
uses.)
*1
Make sure the RTP Start Port (UDP)
and the RTP End Port (UDP) specified
for the router are in the range of the RTP ports that the PBX uses. For the
range of RTP port numbers that the PBX uses, refer to "Port Numbers for
Optional DSP Card" in "8.6 Port Security".
*1
FTP The port number used for the FTP
protocol. This is used for software
updates.
NAT - FTP Server Port No.
(Use the same value as in step 5 of
"Programming the PBX with Built-in
Media Relay Gateway
".)
*1
The port number ranges must be within the range of
RTP/RTCP for NAT traversal (16000–18047).
For the KX-UT series:
Application LAN Side Port Number WAN Side Port Number
SIP Proxy UDP Port No. for SIP Extension
Server
(refer to PC Programming Manual
"9.2.2 PBX Configuration—[1-1]
Configuration
—Slot—System
Property—Site—Port Number")
NAT-SIP Proxy Port No.
(Use the same value as NAT - SIP
Proxy Server Port No. in step 5 of
"Programming the PBX with Built-in
Media Relay Gateway")
CWMP
240 Installation Manual Document Version 2016-03
5.8.4 Installing IP Phones at a Remote Site with a Built-in Media Relay Gateway
