Items Adjustment
Point
Procedure
(D)
*
BBIC
Confirmation
-
1. BBIC Confirmation (Execute the command "getchk").
2. Confirm the returned checksum value.
Connection of checksum value and program number is
shown below.
IC1,
(E) Charge
Control Check
& Charge
Current
Monitor
Confirmation
-
1. Apply 6V between J3(+) and J4(-) with current limit of PSU to 200mA.
2. Confirm that the charge current is ON/OFF.
3. SW to decrease current limit of PSU to 100mA.
4. Confirm that the charge current is stable.
(F)
*
Charge
Detection
(OFF)
Confirmation
-
1. Stop supplying 6V to J3(+) and J4(-).
2. Execute the command "charge".
3. Confirm that the returned value is 0x01 (hex).
(G)
*
Battery
Monitor
Confirmation &
Adjustment
-
1. Apply 2.3V ± 0.005V between BATT(+) and BATT(-).
2. Execute the command "Backloff", then “readbatt“.
3. Confirm: 29 returned value 36 (Hex)
(If the returned value is within the range, no need to do step 4.)
4. If the reading is out of range in step 3 above, adjust the battery monitor excuting
command “wreeprom 00 01 01 XX”. (XX is the reading at step 3.)
Then excute command “wreeprom 00 36 01 YY”. (YY can be confirmed by the following
calculation; YY= XX - 0E)
C3,R81,R24,
(H) Battery low
Confirmation
-
1. Apply 2.40V between BATT(+) and BATT(-).
2. Confirm that there is no flashing of Battery Icon.
3. Apply 2.20V between BATT(+) and BATT(-).
4. Confirm that there is flashing of Battery Icon.
(I)* BBIC Clock
Adjusment
1. Execute the command "conttx".
2. Input Command “rdeeprom 00 57 01”, then you can confirm the current value.
3. Adjust the frequency of CLK executing the command "setfreq xx (where xx is the
value)" so that the reading of the frequency counter is 10.368000MHz ± 10Hz.
Note:
CLK is displayed only for a few seconds when excuting
command "conttx" after the battery is inserted.
