Item Description
Sub Code The 6-digit sub code of the relevant hardware (WXYYZZ).
• W: Shelf type
– Physical shelf: " " (blank)
– Virtual shelf: "*" (asterisk)
• X: Shelf number
KX-TDE100/KX-TDE200: 1
KX-TDE600:
• 1: Basic Shelf
• 2: Expansion Shelf 1
• 3: Expansion Shelf 2
• 4: Expansion Shelf 3
• YY: Slot number
– KX-TDE100 (Physical slot): 00 to 06
(00: IPCMPR Card Slot; 01 to 06: Free Slots)
– KX-TDE200 (Physical slot): 00 to 11
(00: IPCMPR Card Slot; 01 to 11: Free Slots)
– KX-TDE600 (Physical slot):
• Basic Shelf: 00 to 10
(00: IPCEMPR Card Slot; 01 to 10: Free Slots)
• Expansion Shelf: 01 to 12
(01 to 11: Free Slots; 12: BUS-S Card Slot)
– KX-TDE100/KX-TDE200/KX-TDE600
(Virtual slot): 00 to 08
(00: Built-in ESVM card; 01 to 04: Virtual Trunk Slots; 05 to
08: Virtual Extension Slots)
• ZZ: Port number
– For optional service cards except
OPB3 card:
Port number (01 to 16) will be displayed.
– For OPB3 card:
Sub slot number (1 to 3) + port number (1 to 4) will be
displayed as follows:
• Sub slot 1 of OPB3: 11 to 14
• Sub slot 2 of OPB3: 21 to 24
• Sub slot 3 of OPB3: 31 to 34
Note
When there
is no parameter for slot and port number, YY and ZZ
will be displayed as "00".
Example: Sub code for IPCMPR card = " 10000"
Error Message A description of the error.
To view the error log
• From the Utility menu, select Error Log.
78 PC Programming Manual
2.6.8 Utility—Error Log
