4.2 PC Connection
Installation Manual 229
4.2 PC Connection
4.2.1 PC Connection
Connection via MNT Port of IPCMPR Card
IMPORTANT
When connecting a PC to the PBX, a fixed IP address must be assigned to the PC. For
information about fixed IP addresses, ask your network administrator.
Note
For pin assignments and maximum cabling distance, refer to "3.12.1 Connection of Peripherals".
Serial Interface Connection
To LAN Port
MNT Port
PC
To COM Port
RS-232C Port
To Next Page
