Answering System
Preparation
59
For assistance, please call: 1-800-211-PANA(7262)
Telephone System Useful Information
Belt Clip
You can hang the handset on your belt or pocket using the included belt clip.
To attach the belt clip To remove the belt clip
Optional Headset
Connecting an optional headset to the handset allows hands-free phone
conversation. Please use only a Panasonic KX-TCA60, KX-TCA86, KX-TCA88,
KX-TCA88HA, KX-TCA91, KX-TCA92, or KX-TCA98 headset. To order, call the
accessories telephone number on page 2.
Connecting an optional headset
Open the headset jack cover, and insert the headset plug into the headset jack as
shown below.
• Headset sold separately. Model shown here is KX-TCA88.
To switch to the speakerphone while using the headset:
Press [s]. To return to the headset, press [C].
B
A
While pressing the top of the clip (1),
pull the right edge in the direction of
the arrow (
2).
Headset Jack
TG5230.fm Page 59 Wednesday, February 4, 2004 9:51 AM
