Panasonic KX-TGH262B - Handset Replacement Parts List; Handset Cabinet and External Parts List; Handset Internal Component Parts List

92
KX-TGH260/KX-TGH262/KX-TGH263/KX-TGH264/KX-TGHA20/KX-TGA20
16.5.1.3. Operational P.C. Board Parts
16.5.2. Handset
16.5.2.1. Cabinet and Electrical Parts
Note:
(*1) When replacing the handset LCD, See How to
Replace the Handset LCD (P.51).
R160 ERJ3GEYJ821 820 S
R162 ERJ3GEYJ473 47k S
R163 D0GG390JA007 39
R164 ERJ3GEYJ272 2. 7 k S
R165 ERJ3GEYJ273 27k S
R166 ERJ3GEYJ822 8. 2 k S
R168 ERJ3GEYJ472 4. 7 k S
R178 ERJ2GEJ332 3 .3 k S
R311 ERJ2GEJ103 10k S
R321 ERJ2RKF1400 140 S
R322 ERJ2RKF1000 100 S
R351 ERJ2GEJ333 33k S
R352 ERJ2GEJ682 6 .8 k S
R354 ERJ2GEJ123
12k S
R355 ERJ2GEJ681 680 S
R356 ERJ2GEJ103 10k S
R371 ERJ8GEYJ1R0 1 S
R372 ERJ8GEYJ1R0 1 S
R373 ERJ2GEJ681 680 S
R477 ERJ2GEJ1R0 1 S
R478 ERJ2GEJ1R0 1 S
R501 ERJ2RKF5602 56k
R502 ERJ2GEJ332 3 .3 k S
R505 ERJ2GEJ102 1k S
R601 ERJ2GEJ332 3 .3 k S
R653 ERJ2GE0R00 0 S
R702 ERJ2GEJ103
10k S
R721 ERJ2GEJ103 10k S
R731 ERJ2GEJ104 1 00 k S
R732 ERJ2GEJ224 2 20 k S
R733 ERJ2GEJ104 1 00 k S
R734 ERJ2GEJ224 2 20 k S
R735 ERJ2GEJ223 22k S
(CAPACITORS)
C101 F1K2H681A008 CERAMIC CAPACITOR S
C102 F1K2H681A008 CERAMIC CAPACITOR S
C103 ECUV1H103KBV 0.01
C104 ECUV1H103KBV 0.01
C105 F1K2H681A008
CERAMIC CAPACITOR S
C106 F1K2H681A008 CERAMIC CAPACITOR S
C109 ECUE1H821KBQ 820 p
C110 ECUE1H821KBQ 820 p
C111 ECUE1A333KBQ 0.033
C113 ECUE1A823KBQ 0.082
C115 ECUV1C104KBV 0.1
C116 ECUV1C104KBV 0.1
C142 ECUV1H103KBV 0.01
C152 ECUE1C103KBQ 0.01
C161 F1K1E1060001 CERAMIC CAPACITOR
C167 ECUV1H102KBV 0.001
C171 ECUV1C223KBV 0.022
C173 ECUE1A104KBQ 0.1
C174 ECUE1H222KBQ 0.0022
C184 ECUV1C105KBV 1
C311 ECUE0J105KBQ 1
C321 ECUV1C105KBV 1
C341 F2G0J331A146 330
C342 ECUE1A104KBQ 0.1
C344 F2G0J102A148 1000
C351 ECUV1C105KBV 1
C472 ECUE1H100DCQ 10p
C473 ECUE1H100DCQ 10p
C477 ECUE1H222KBQ 0.0022
C478 ECUE1H222KBQ 0.0022
C501 ECUE1A104KBQ 0.1
C502 ECUE0J105KBQ
1
C503 ECUE1H100DCQ 10p
C504 ECUE1A104KBQ 0.1
C505 ECUE1A104KBQ 0.1
C506 ECUV0J225KBV 2.2
C508 ECUE0J105KBQ 1
C509 ECUE0J105KBQ 1
C512 ECUE0J105KBQ 1
Safety Ref.
No.
Part No. Part Name & Description Remarks
C513 ECUE1A104KBQ 0.1
C514 ECUE1H100DCQ 10p
C515 ECUE1A104KBQ 0.1
C516 ECUE1A104KBQ 0.1
C518 ECUE1A104KBQ 0.1
C519 ECUE1A104KBQ 0.1
C520 ECUE1H100DCQ 10p
C601 ECUE1A104KBQ 0.1
C611 ECUE1A104KBQ 0.1
C721 ECUE1A104KBQ 0.1
C722 ECUV1C105KBV 1
C723 ECUV1C105KBV 1
C851 ECUE1H100DCQ 10p
C859 ECUE1H100DCQ 10p
C860 F1G1HR70A765 CERAMIC CAPACITOR
C862 F1G1H2R4A765 CERAMIC CAPACITOR
(OTHERS)
F301 K5H302Y00003 FUS E
L781 G1C4N7Z00006 COI L
P101 D4DAY220A022 THERMISTOR
X501 H0J103500037 CRYSTAL OSCILLATOR (*1)
Safety Ref.
No.
Part No. Part Name & Description Remarks
PCB2 PNWP2TGH260H OPERATIONAL P.C.BOARD
ASS’Y (RTL)
(LEDS)
LED901 B3AAB0000347 LED
LED902 B3AAB0000347 LED
LED904 B3ABB0000331 LED
LED905 B3ABB0000331 LED
LED906 B3ABB0000331 LED
(SWITCHES)
SW901 K0H1BA000578 SPECIAL SWITCH
SW902 K0H1BA000578 SPECIAL SWITCH
SW903 K0H1BA000578 SPECIAL SWITCH
SW904 K0H1BA000578 SPECIAL SWITCH
SW905 K0H1BA000578 SPECIAL SWITCH
SW906 K0H1BA000578 SPECIAL SWITCH
SW907 K0H1BA000578 SPECIAL SWITCH
SW908 K0H1BA000578 SPECIAL SWITCH
Safety Ref.
No.
Part No. Part Name & Description Remarks
101 PNGP1318Z1 PANEL, LCD PMMA-HB
102 PNYE1123Z TAPE, DOUBLE SIDED
103 PNKM1529Z1 CABINET BODY PC+ABS-
HB
104 L0AA02A00119 R E C E I V E R
105 PNYE1122Z SPACER, CUSHION LCD
106 L5EDDYY00590 LIQUID CRYSTAL DISPLAY
(*1)
107 PNYT1036Z1 KEYBOARD SWITCH ABS-HB
108 PQHG10729Z RUBBER PARTS, RECEIVER
109 PNHR1923Z GUIDE, RECEIVER
110 PNLA1121Z A NT E N N A
111 PNHX1751Z PLASTIC, COVER INSIDE
112 PNMH1308Z GUIDE, SPEAKER METAL
113 L0AA01A00158 S PE AK ER
114 PNHS1502Z SPACER, SPEAKER NET
115 PNHX1759Z
PLASTIC, COVER OUTSIDE
116 PNGT7993Z N A M E P L A T E , A L
117 PNQT2006Z LABEL , BATTERY
Safety Ref.
No.
Part No. Part Name & Description Remarks
