11 Graphic object
DXF versions R12J, R13J, R14
Element Graphic name Validity Remark
TEXT Character · The font of the TEXT element is
replaced with the laser marker
font. In the marking data, the
TEXT element is disassembled
and converted into lines.
You cannot treat it as a character
object.
TRACE Bold line –
VERTEX Vertex · VERTEX in combination with
POLYLINE is available.
VIEWPORT View port –
 
DXF version R13J, R14
Element Graphic name Validity Remark
3DSOLID 3D paint –
ACAD_PROXY_ENTITY Proxy graphic –
BODY Body –
ELLIPSE Ellipse ·
IMAGE Image –
LEADER Lead line –
LWPOLYLINE Lightweight polyline · Bold line is not supported.
MLINE Multi-line –
MTEXT Multi-text · The font of the MTEXT element
is replaced with the laser marker
font. In the marking data, the
MTEXT element is disassembled
and converted into lines.
You cannot treat it as a character
object.
OLEFRAME OLE frame –
OLE2FRAME OLE2 frame –
RAY Radiation (half line) ·
REGION Region –
SPLINE Free curve ·
TOLERANCE Geometric tolerance –
XLINE Line (straight line) ·
 
