15 2D code object
• “Horizontal quiet zone to module width ratio”:
Set the ratio of quiet zone width to module width.
• “Vertical quiet zone to module width ratio”:
Set the ratio of quiet zone height to module width.
• “Error correction level”:
PDF417 has error correction capability to restore data if the code is dirty or damaged.
Select one of nine error correction levels.
If “Auto” is selected, the optimal error correction level is set automatically depending on
the code data and the settings for compaction mode.
• “Total width [mm]”, “Total height [mm]”:
Displays the entire width and height of the PDF417 code, including the quiet zone.
Filling line spacing:
• To set the distance between the marking lines, enter a value for “Bar code filling line
spacing [mm]” in the “Object group” settings.
Related topics
Create a 2D code object (page 167)
2D code types (page 155)
Rotate a 2D code object (page 172)
Specify the position of a 2D code object (page 172)
Set laser correction parameters for a marking object (page 238)
Set object group parameters (page 193)
15.16.2 Invert a PDF417 code
The “Invert” setting inverts the colors of a PDF417 code (white spaces become black, and
black bars become white).
1. To edit the parameters of the PDF417 code, select the object in the object list or in the
marking image editor.
The parameters are displayed in the category below the object list.
2. To invert the PDF417 code, select “Invert” under “Module”.
When the check box is selected, the spaces between bars, and the quiet zone are
marked.
Example of a normal PDF417 code
182 ME-NAVIS2-OP-1
