23 On-the-fly marking
23 On-the-fly marking
23.1 About on-the-fly-marking
Specify on-the-fly marking settings if you want to mark a workpiece in motion, e.g. a
workpiece that move on an assembly line.
On-the-fly marking is available for LP-RC, LP-RF and LP-RV.
The parameters for on-the-fly marking are located on the “Marking settings” screen in the
“On-the-fly marking” tab.
The following functions are not available for on-the-fly marking:
• “File settings” > “Image checking before marking”, “Image checking after marking”
• “Object group” > “Overwriting interval [s]”
• 2D code: “Object settings” > “Module marking order” > “Skip one”, “Skip two”
To enable on-the-fly marking and display the settings, select “ON” for “On-the-fly marking”.
Select “OFF” to disable the function.
Under “On-the-fly settings for all files”, specify the basic parameters. The settings apply to all
files in the laser marking system.
Under “On-the-fly settings for one file”, specify the detailed parameters. The settings apply
only to the current file.
Vibrations coming from surrounding equipment or line speed fluctuations may affect the marking
quality of bar codes or 2D codes during on-the-fly marking. When marking a bar code or 2D code on
a moving workpiece, check that the marking and reading results of the marked code are of sufficient
high quality.
Related topics
On-the-fly marking settings for all files (page 241)
On-the-fly-marking settings for one file (page 244)
Trigger mode parameters (page 247)
Line speed control setting “2 sensors input” (page 249)
Specify on-the-fly marking settings (page 249)
240 ME-NAVIS2-OP-1
