30
DVQX2185 (ENG)
Getting Started / Basic Operations
Attaching a Lens
Lenses That Can Be Used
This unit can use the dedicated lenses
compatible with the Micro Four Thirds™
System lens mount specification (Micro Four
Thirds mount).
You can also use the Leica M Mount
interchangeable lens by attaching the M
Mount Adaptor (DMW-MA2M: optional).
• Refer to catalogs/websites for most current information
regarding supported lenses.
https://panasonic.jp/support/global/cs/dsc/
(English only)
A
A
Lens fitting marks
Removing a Lens
• While pressing the lens release button
B
, rotate
the lens in the direction of the arrow until it stops
and then remove it.
B
• After removing the lens, be sure to attach the body cap and the lens rear cap.
To Next Page
