Panasonic Lumix DMC-GF7 User Manual

7. Functions Customised for Various Subjects and Purposes
174
• This function is not for use in a security camera.
• If you leave the unit somewhere to perform [Time Lapse Shot], please be careful of theft.
• Recording for long periods in cold places such as ski resorts or places at high altitude,
or in warm, wet environments may cause a malfunction, so please be careful.
• Recording may not be consistent with the set recording interval or the set number of pictures
depending on recording conditions.
• We recommend that you use a sufficiently charged battery or an AC adaptor (optional) and a
DC coupler (optional).
• [Time Lapse Shot] is paused in the following cases.
– When the charge on the battery runs out
– Turning the camera off
During [Time Lapse Shot], you can replace the battery and the card, and then restart by turning
on this unit. (Note that pictures taken after the restart will be saved as a separate set of group
pictures) Turn off this unit when replacing the battery or the card.
• Do not connect the AV cable (optional), the HDMI micro cable, or the USB connection cable
(supplied) during Time Lapse Shooting.
• When a picture quality different from the aspect ratio of the original pictures is selected, black
strips will be displayed on the top and bottom or the left and right of the motion picture.
• If while recording motion pictures using the AC adaptor (optional) the power supply is cut off
due to a power cut or if the AC adaptor (optional) is disconnected etc., the motion picture will
not be recorded.
• A motion picture that exceeds the recording time of 29 minutes and 59 seconds and a motion
picture that exceeds the file size of 4 GB cannot be created.
• A motion picture shorter than 1 second is displayed as “0s” on the motion picture recording time
(P219)
.
•
When only one picture is taken, it will not be saved as a group picture.
Not available in these cases:
•
This function is not available in the following cases:
– In Self Shot Mode
– [Handheld Night Shot] (Scene Guide Mode)
– When using [Multi Exp.]
– When using [Stop Motion Animation]

Panasonic Lumix DMC-GF7 Specifications

General

Megapixel	16 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Lens
Still image resolution(s)	4592x3448 3232x2424 2272x1704 1824x1368 4592x3064 3232x2160 2272x1520 1824x1216 4592x2584 3840x2160 1920x1080 1824x1024 3424x3424 2416x2416 1712x1712
Power source type	Battery
Battery voltage	7.2 V
Battery life (max)	680 h
Battery life (CIPA standard)	230 shots
Filter size	37 mm
Digital zoom	4 x
Optical zoom	- x
Focal length range	12 - 32 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	22
Minimum aperture number	3.5
Number of diaphragm blades	7
Lens structure (elements/groups)	8/7
Maximum focal length (35mm film equiv)	64 mm
Minimum focal length (35mm film equiv)	24 mm
Product color	White
Focus adjustment	Auto
Auto focusing (AF) modes	Centre weighted Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.2 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	0.02 s
Flash guide number	5.6 m
Flash range (wide)	- m
Flash exposure correction	±2EV (1/3 EV step)
Cables included	USB
Bundled software	PHOTOfunSTUDIO 9.6 PE SILKYPIX Developer Studio 4.2 SE LoiLoScope
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@25fps, 640x480@30fps, 1280x720@25fps, 1280x720@30fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Audio system	stereo
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Second display	No
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
USB version	2.0
HDMI connector type	Micro
Bluetooth	-
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Children, Night, Night portrait, Panorama, Portrait
Image editing	Crop, Resizing, Rotating
Photo effects	Black&White, Skin tones, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Shade
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Languages support	Multi
Playback zoom (max)	16 x

Weight and Dimensions

Depth	33.3 mm
Width	106.5 mm
Height	64.6 mm
Weight	236 g
Lens weight	70 g
Lens diameter	55.5 mm
Weight (including battery)	336 g
