To Reinstall:
➢ Align the slots on the pre-filter with
the alignment tabs inside dust cup
lid assembly.
➢ Rotate pre-filter clockwise to lock in
place.
➢ Replace the lower portion of the
dust cup by aligning marks as
shown, UNLOCKED (For Cleaning).
➢ Rotate while pressing downward
until marks align as shown;
LOCKED (For Use).
➢ Reinstall the dust cup. (See DUST
CUP, p. 22)
