Panasonic NC-TWS30 User Manual

- 8 -
NC-TWS30
Bottom ring
Peg frame
Tapping screw
(M4 x 12)
Minus
screwdriver
Fig. 8
2.7. Peg frame
1. Remove Body follow the instruction.
2. Remove Bottom ring upside with minus screwdriver
or etc.
3. Remove 1 screw off.
4. Use minus screwdriver to pry between 2 ribs of Peg
frame and Body, and then push out Peg frame with
thumb, then pull it off.
2.8. Gauge cover
Press clear part of Gauge Cover from inner body by
thumb and remove it.
Body
Push by thumb
Gauge cover
Fig. 9
