15.6. Bundled Parts List
(The parts for left opening are not used when the doors made right opening with the appliance.)
Ref.No Part No Part Name & Description
Pcs./
Model
Remark U
200 CNRBH-142660 PACKING PARTS AS 1 Bundled parts,from 201 to 212
201 CNRAE-140540 HINGE TOP L 1
202 CNRAE-138150 HINGE CENTER L 1
203 CNRAE-140570 HINGE BOTTOM L 1
204 CNRAE-140520 STOPPER DOOR L 2
205 CNRAE-137770 LATCH DOOR L 2
206 CNRAC-228530 COVER HINGE TOP L(X) 1
207 CNRAD-348470 COVER CAP DOOR PCT R(X) 1
208 CNRAC-228550 COVER TABLE R(X) 1
209 CNRAE-127730 PIN HINGE CENTER 1
210 CNRAC-228690 COVER HOLE HINGE 1
211 CNRAH-242670 LABEL PANEL FRONT BOT 1
212 —— CASE GREASE AS 1
