Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 141
signal is disrupted and automatically switches to the backup input. In this case, it is not possible to switch to the backup input signal until the
original input signal is restored. If the input has switched to the backup input automatically, it is possible to switch to the backup input signal
when the original signal has been restored. In this case, the current input is maintained.
f
The primary input setting values are applied to image adjustment values such as the [PICTURE] menu
→
[PICTURE MODE], [GAMMA],
and [COLOR TEMPERATURE].
f
When the combination of inputs in [BACKUP INPUT MODE] is the SDI input and DVI-D input or the SDI input and HDMI input, the backup
function is enabled only in the following combination of signals.
Primary input
[SDI]
Secondary input
[DVI-D]/[HDMI]
HD-SDI 720/60p YP
B
P
R
4:2:2 720/60p YP
B
P
R
4:4:4
HD-SDI 720/50p YP
B
P
R
4:2:2 720/50p YP
B
P
R
4:4:4
3G-SDI 1080/60i RGB 1080/60i RGB
3G-SDI 1080/50i RGB 1080/50i RGB
3G-SDI 1080/24p RGB 1080/24p RGB
3G-SDI 1080/25p RGB 1080/25p RGB
3G-SDI 1080/30p RGB 1080/30p RGB
3G-SDI 1080/60p YP
B
P
R
4:2:2 1080/60p YP
B
P
R
4:4:4
3G-SDI 1080/50p YP
B
P
R
4:2:2 1080/50p YP
B
P
R
4:4:4
Using the DVI-D input and HDMI input
1) Press
as
to select [NO SIGNAL SETTING].
2) Press the <ENTER> button.
f
The
[NO SIGNAL SETTING]
screen is displayed.
3) Press
as
to select [BACKUP INPUT SETTING].
4) Press the <ENTER> button.
f
The
[BACKUP INPUT SETTING]
screen is displayed.
5) Press
as
to select [BACKUP INPUT MODE].
6) Press the <ENTER> button.
f
The
[BACKUP INPUT MODE]
screen is displayed.
7) Press
as
to select the combination of the DVI-D input and HDMI input and press the <ENTER>
button.
8) Press the <MENU> button.
f
The
[BACKUP INPUT SETTING]
screen is displayed.
9) Press
as
to select [AUTOMATIC SWITCHING].
f
[AUTOMATIC SWITCHING] cannot be selected when [BACKUP INPUT MODE] is set to [OFF].
10) Press
qw
to switch the item.
f
The items will switch each time you press the button.
[ENABLE]
Switches to the secondary input automatically when the input signal for primary input is disrupted.
[DISABLE]
Disables the automatic input switching function.
Note
f
The [BACKUP INPUT SETTING] setting item is common with the following menu item.
g
The [DISPLAY OPTION] menu
→
[BACKUP INPUT SETTING]
f
The backup function is enabled when [BACKUP INPUT MODE] is set to anything other than [OFF] and same signal is input to the primary
input and the secondary input.
f
To switch to the backup input signal using the backup function, make sure that the following three conditions are satised to be ready to use
the function.
g
Set [BACKUP INPUT MODE] to a combination of the DVI-D input and HDMI input.
g
Input the same signal to the primary and secondary inputs.
g
Display the image of the primary input.
f
In the following cases, the state of readiness is canceled. To switch to the backup input signal using the backup function, switch to the
primary input and enter the state of readiness.
g
When switching to an input other than the primary input from the state of readiness
